使用axis自动生成webservice客户端代码.docx

利用AXIS生成客户端文件，使得开发webservice更加简单，以下是我的个人代码，
工具：
Myeclipse7.0，axis1.4，tomcat5.5，jdk1.5
一、 下载axis的jar包，我的是axis-bin-1_4.zip包，解压后有axis的lib目录，一会儿我们要用，
二、 在myeclip se中创建自己的webservice工程，这个在的文库里有，
三、 在C盘目录下创建一个批处理文件，我的名字是wsdltojava.bat，内容如下：
set Axis_Lib=E:\jar\axis\asixTool\axis-bin-1_4\axis-1_4\lib
set Java_Cmd=java -Djava.ext.dirs=%Axis_Lib%
set Axis_Servlet=http://localhost:8090/myAxis/services/HelloWorld?wsdl
%Java_Cmd% org.apache.axis.wsdl.WSDL2Java -u %Axis_Servlet%
备注：红色字体我的axis的目录，也就是刚才我解压出来的axis，
蓝色是我的webservice的访问地址，其他的不用处理，
然后双击这个文件，产生以下几个文件：
（1）、目录是：C:\localhost\myAxis\services\HelloWorld
（2）、

四、 将这四个文件拷贝到你的客户端，创建客户端

运行即可

附录代码：
服务端
HelloWorld.java
package webservice.axis.test;

public class HelloWorld {
public String hello(){
return "Hello "+"aaaaaaaaaaaaaaaaaa";
}
}

客户端（通过刚才命令生成的四个文件）
HelloWorld.java
/**
* HelloWorld.java
*
* This file was auto-generated from WSDL
* by the Apache Axis 1.4 Apr 22, 2006 (06:55:48 PDT) WSDL2Java emitter.
*/

package webservice.axis.test.batClient;

public interface HelloWorld extends java.rmi.Remote {
public java.lang.String hello() throws java.rmi.RemoteException;
}

HelloWorldService.java

/**
* HelloWorldService.java
*
* This file was auto-generated from WSDL
* by the Apache Axis 1.4 Apr 22, 2006 (06:55:48 PDT) WSDL2Java emitter.
*/

package webservice.axis.test.batClient;

public interface HelloWorldService extends javax.xml.rpc.Service {
public java.lang.String getHelloWorldAddress();

public webservice.axis.test.batClient.HelloWorld getHelloWorld() throws javax.xml.rpc.ServiceException;

public webservice.axis.test.batClient.HelloWorld getHelloWorld(.URL portAddress) throws javax.xml.rpc.ServiceException;
}

HelloWorldServiceLocator.java
/**
* HelloWorldServiceLocator.java
*
* This file was auto-generated from WSDL
* by the Apache Axis 1.4 Apr 22, 2006 (06:55:48 PDT) WSDL2Java emitter.
*/

package webservice.axis.test.batClient;

public class HelloWorldServiceLocator extends org.apache.axis.client.Service implements webservice.axis.test.batClient.HelloWorldService {

public HelloWorldServiceLocator() {
}

public HelloWorldServiceLocator(org.apache.axis.EngineConfiguration config) {
super(config);
}

public HelloWorldServiceLocator(java.lang.String wsdlLoc, javax.xml.namespace.QName sName) throws javax.xml.rpc.ServiceException {
super(wsdlLoc, sName);
}

// Use to get a proxy class for HelloWorld
private java.lang.String HelloWorld_address = "http://localhost:8090/myAxis/services/HelloWorld";

public java.lang.String getHelloWorldAddress() {
return HelloWorld_address;
}

// The WSDD service name defaults to the port name.
private java.lang.String HelloWorldWSDDServiceName = "HelloWorld";

public java.lang.String getHelloWorldWSDDServiceName() {
return HelloWorldWSDDServiceName;
}

public void setHelloWorldWSDDServiceName(java.lang.String name) {
HelloWorldWSDDServiceName = name;
}

public webservice.axis.test.batClient.HelloWorld getHelloWorld() throws javax.xml.rpc.ServiceException {
.URL endpoint;
try {
endpoint = new .URL(HelloWorld_address);
}
catch (.MalformedURLException e) {
throw new javax.xml.rpc.ServiceException(e);
}
return getHelloWorld(endpoint);
}

public webservice.axis.test.batClient.HelloWorld getHelloWorld(.URL portAddress) throws javax.xml.rpc.ServiceException {
try {
webservice.axis.test.batClient.HelloWorldSoapBindingStub _stub = new webservice.axis.test.batClient.HelloWorldSoapBindingStub(portAddress, this);
_stub.setPortName(getHelloWorldWSDDServiceName());
return _stub;
}
catch (org.apache.axis.AxisFault e) {
return null;
}
}

public void setHelloWorldEndpointAddress(java.lang.String address) {
HelloWorld_address = address;
}

/**
* For the given interface, get the stub implementation.
* If this service has no port for the given interface,
* then ServiceException is thrown.
*/
public java.rmi.Remote getPort(Class serviceEndpointInterface) throws javax.xml.rpc.ServiceException {
try {
if (webservice.axis.test.batClient.HelloWorld.class.isAssignableFrom(serviceEndpointInterface)) {
webservice.axis.test.batClient.HelloWorldSoapBindingStub _stub = new webservice.axis.test.batClient.HelloWorldSoapBindingStub(new .URL(HelloWorld_address), this);
_stub.setPortName(getHelloWorldWSDDServiceName());
return _stub;
}
}
catch (java.lang.Throwable t) {
throw new javax.xml.rpc.ServiceException(t);
}
throw new javax.xml.rpc.ServiceException("There is no stub implementation for the interface: " + (serviceEndpointInterface == null ? "null" : serviceEndpointInterface.getName()));
}

/**
* For the given interface, get the stub implementation.
* If this service has no port for the given interface,
* then ServiceException is thrown.
*/
public java.rmi.Remote getPort(javax.xml.namespace.QName portName, Class serviceEndpointInterface) throws javax.xml.rpc.ServiceException {
if (portName == null) {
return getPort(serviceEndpointInterface);
}
java.lang.String inputPortName = portName.getLocalPart();
if ("HelloWorld".equals(inputPortName)) {
return getHelloWorld();
}
else {
java.rmi.Remote _stub = getPort(serviceEndpointInterface);
((org.apache.axis.client.Stub) _stub).setPortName(portName);
return _stub;
}
}

public javax.xml.namespace.QName getServiceName() {
return new javax.xml.namespace.QName("http://localhost:8090/myAxis/services/HelloWorld", "HelloWorldService");
}

private java.util.HashSet ports = null;

public java.util.Iterator getPorts() {
if (ports == null) {
ports = new java.util.HashSet();
ports.add(new javax.xml.namespace.QName("http://localhost:8090/myAxis/services/HelloWorld", "HelloWorld"));
}
return ports.iterator();
}

/**
* Set the endpoint address for the specified port name.
*/
public void setEndpointAddress(java.lang.String portName, java.lang.String address) throws javax.xml.rpc.ServiceException {

if ("HelloWorld".equals(portName)) {
setHelloWorldEndpointAddress(address);
}
else
{ // Unknown Port Name
throw new javax.xml.rpc.ServiceException(" Cannot set Endpoint Address for Unknown Port" + portName);
}
}

/**
* Set the endpoint address for the specified port name.
*/
public void setEndpointAddress(javax.xml.namespace.QName portName, java.lang.String address) throws javax.xml.rpc.ServiceException {
setEndpointAddress(portName.getLocalPart(), address);
}

}

HelloWorldSoapBindingStub.java

/**
* HelloWorldSoapBindingStub.java
*
* This file was auto-generated from WSDL
* by the Apache Axis 1.4 Apr 22, 2006 (06:55:48 PDT) WSDL2Java emitter.
*/

package webservice.axis.test.batClient;

public class HelloWorldSoapBindingStub extends org.apache.axis.client.Stub implements webservice.axis.test.batClient.HelloWorld {
private java.util.Vector cachedSerClasses = new java.util.Vector();
private java.util.Vector cachedSerQNames = new java.util.Vector();
private java.util.Vector cachedSerFactories = new java.util.Vector();
private java.util.Vector cachedDeserFactories = new java.util.Vector();

static org.apache.axis.description.OperationDesc [] _operations;

static {
_operations = new org.apache.axis.description.OperationDesc[1];
_initOperationDesc1();
}

private static void _initOperationDesc1(){
org.apache.axis.description.OperationDesc oper;
org.apache.axis.description.ParameterDesc param;
oper = new org.apache.axis.description.OperationDesc();
oper.setName("hello");
oper.setReturnType(new javax.xml.namespace.QName("http://www.w3.org/2001/XMLSchema", "string"));
oper.setReturnClass(java.lang.String.class);
oper.setReturnQName(new javax.xml.namespace.QName("", "helloReturn"));
oper.setStyle(org.apache.axis.constants.Style.RPC);
oper.setUse(org.apache.axis.constants.Use.ENCODED);
_operations[0] = oper;

}

public HelloWorldSoapBindingStub() throws org.apache.axis.AxisFault {
this(null);
}

public HelloWorldSoapBindingStub(.URL endpointURL, javax.xml.rpc.Service service) throws org.apache.axis.AxisFault {
this(service);
super.cachedEndpoint = endpointURL;
}

public HelloWorldSoapBindingStub(javax.xml.rpc.Service service) throws org.apache.axis.AxisFault {
if (service == null) {
super.service = new org.apache.axis.client.Service();
} else {
super.service = service;
}
((org.apache.axis.client.Service)super.service).setTypeMappingVersion("1.2");
}

protected org.apache.axis.client.Call createCall() throws java.rmi.RemoteException {
try {
org.apache.axis.client.Call _call = super._createCall();
if (super.maintainSessionSet) {
_call.setMaintainSession(super.maintainSession);
}
if (super.cachedUsername != null) {
_call.setUsername(super.cachedUsername);
}
if (super.cachedPassword != null) {
_call.setPassword(super.cachedPassword);
}
if (super.cachedEndpoint != null) {
_call.setTargetEndpointAddress(super.cachedEndpoint);
}
if (super.cachedTimeout != null) {
_call.setTimeout(super.cachedTimeout);
}
if (super.cachedPortName != null) {
_call.setPortName(super.cachedPortName);
}
java.util.Enumeration keys = super.cachedProperties.keys();
while (keys.hasMoreElements()) {
java.lang.String key = (java.lang.String) keys.nextElement();
_call.setProperty(key, super.cachedProperties.get(key));
}
return _call;
}
catch (java.lang.Throwable _t) {
throw new org.apache.axis.AxisFault("Failure trying to get the Call object", _t);
}
}

public java.lang.String hello() throws java.rmi.RemoteException {
if (super.cachedEndpoint == null) {
throw new org.apache.axis.NoEndPointException();
}
org.apache.axis.client.Call _call = createCall();
_call.setOperation(_operations[0]);
_call.setUseSOAPAction(true);
_call.setSOAPActionURI("");
_call.setSOAPVersion(org.apache.axis.soap.SOAPConstants.SOAP11_CONSTANTS);
_call.setOperationName(new javax.xml.namespace.QName("http://test.axis.webservice", "hello"));

setRequestHeaders(_call);
setAttachments(_call);
try { java.lang.Object _resp = _call.invoke(new java.lang.Object[] {});

if (_resp instanceof java.rmi.RemoteException) {
throw (java.rmi.RemoteException)_resp;
}
else {
extractAttachments(_call);
try {
return (java.lang.String) _resp;
} catch (java.lang.Exception _exception) {
return (java.lang.String) org.apache.axis.utils.JavaUtils.convert(_resp, java.lang.String.class);
}
}
} catch (org.apache.axis.AxisFault axisFaultException) {
throw axisFaultException;
}
}

}

最后要感谢网上资源
