变压器损失计算数据型号容量空载损失短路损失空载电流短路电压有功不变损失无功不变损失有功损失常数无功损失常数 S7 80 0.27 1.65 2.40 4.50 194 1382 1.2890625 2.8125000 S7 100 0.32 2.00 2.30 4.50 230 1656 1.0000000 2.2500000 S7 160 0.46 2.85 2.10 4.50 331 2419 0.5566406 1.4062500 S7 200 0.54 3.40 2.10 4.50 389 3024 0.4250000 1.1250000 S7 250 0.64 4.00 2.00 4.50 461 3600 0.3200000 0.9000000 S7 315 0.76 4.80 2.00 4.50 547 4536 0.2418745 0.7142857 S7 400 0.92 5.80 1.90 4.50 662 5482 0.1812500 0.5625000 S7 500 1.08 6.90 1.90 4.50 778 6840 0.1380000 0.4500000 S7 630 1.40 8.50 1.80 5.50 1008 8165 0.1070799 0.4365079 S7 800 1.66 10.40 1.80 5.50 1195 10368 0.0812500 0.3437500 S7 1000 1.93 12.18 1.70 5.50 1390 12240 0.0609000 0.2750000 S7 1250 2.35 14.49 1.60 5.50 1692 14400 0.0463680 0.2200000 S7 1600 3.00 17.30 1.50 5.50 2160 17280 0.0337891 0.1718750 S9 30 0.13 0.60 2.10 4.00 94 454 3.3333333 6.6666667 S9 50 0.17 0.87 2.00 4.00 122 720 1.7400000 4.0000000 S9 63 0.20 1.04 1.90 4.00 144 862 1.3101537 3.1746032 S9 80 0.24 1.25 1.80 4.00 173 1037 0.9765625 2.5000000 S9 100 0.29 1.50 1.60 4.00 209 1152 0.7500000 2.0000000 S9 125 0.34 1.80 1.50 4.00 245 1350 0.5760000 1.6000000 S9 160 0.40 2.20 1.40 4.00 288 1613 0.4296875 1.2500000 S9 200 0.48 2.60 1.30 4.00 346 1872 0.3250000 1.0000000 S9 250 0.56 3.05 1.20 4.00 403 2160 0.2440000 0.8000000 S9 315 0.67 3.65 1.10 4.00 482 2495 0.1839254 0.6349206 S9 400 0.80 4.30 1.00 4.00 576 2880 0.1343750 0.5000000 S9 500 0.96 5.10 1.00 4.00 691 3600 0.1020000 0.4000000 S9 630 1.20 6.20 0.90 4.50 864 4082 0.0781053 0.3571429 S9 800 1.40 7.50 0.80 4.50 1008 4608 0.0585938 0.2812500 S9 1000 1.70 10.30 0.70 4.50 1224 5040 0.0515000 0.2250000 S9 1250 1.95 12.00 0.60 4.50 1404 5400 0.0384000 0.1800000 S9 1600 2.40 14.50 0.60 4.50 1728 6912 0.0283203 0.1406250 SJ 100 0.73 2.40 7.50 4.50 526 5400 1.2000000 0.2500000 SJ 135 1.00 3.15 7.50 4.50 720 7290 0.8641975 1.6666667 SJ 180 1.20 4.10 7.00 4.50 864 9072 0.6327160 1.2500000 SJ 240 1.60 5.10 7.00 4.50 1152 12096 0.4427083 0.9375000 SJ 320 1.90 6.20 7.00 4.50 1368 16128 0.3027344 0.7031250 SJ 560 2.50 9.40 6.00 4.50 1800 24192 0.1498724 0.4017857 SJ 750 4.10 11.90 6.00 4.50 2952 32400 0.1057778 0.3000000 SJ 1000 4.90 15.00 5.00 4.50 3528 36000 0.0750000 0.2250000 SJ 1350 6.00 19.50 5.00 4.50 4320 48600 0.0534979 0.1666667 SJ 1800 8.00 24.00 4.50 4.50 5760 58320 0.0370370 0.1250000 SJ 3200 11.00 37.00 4.00 5.50 7920 92160 0.0180664 0.0859375 SJ 4200 14.00 47.00 4.00 5.50 10080 120960 0.0133220 0.0654762 SJ 5600 18.00 56.00 4.00 5.50 12960 161280 0.0089286 0.0491071 SL 100 0.62 2.25 7.50 4.00 446 5400 1.1250000 2.0000000 SL 125 0.74 2.70 7.50 4.00 533 6750 0.8640000 1.6000000 SL 160 0.87 3.30 7.00 4.00 626 8064 0.6445313 1.2500000 SL 200 1.00 3.90 7.00 4.00 720 10080 0.4875000 1.0000000 SL 250 1.20 4.60 6.50 4.00 864 11700 0.3680000 0.8000000 SL 315 1.45 5.60 6.50 4.00 1044 14742 0.2821869 0.6349206 SL 400 1.75 6.70 6.50 4.00 1260 18720 0.2093750 0.5000000 SL 500 2.05 8.20 6.00 4.00 1476 21600 0.1640000 0.4000000 SL 630 2.45 10.00 6.00 4.50 1764 27216 0.1259763 0.3571429 SL 800 3.15 12.00 5.50 4.50 2268 31680 0.0937500 0.2812500 SL 1000 3.70 14.50 5.00 4.50 2664 36000 0.0725000 0.2250000 SL 1250 4.35 17.50 5.00 4.50 3132 45000 0.0560000 0.1800000 SL 1600 5.30 20.50 4.50 4.50 3816 51840 0.0400391 0.1406250 SL 2000 6.30 24.50 4.50 4.50 4536 64800 0.0306250 0.1125000 SL 2500 7.40 28.50 4.50 5.50 5328 81000 0.0228000 0.1100000 SL 3150 7.80 33.50 4.00 5.50 5616 90720 0.0168808 0.0873016 SL 4000 10.40 39.50 4.00 5.50 7488 115200 0.0123438 0.0687500 SL 5000 12.50 47.30 4.00 5.50 9000 144000 0.0094600 0.0550000 SL 6300 14.80 56.00 4.00 5.50 10656 181440 0.0070547 0.0436508
