常用的制图专业术语，中、英文对照 A-L
A
A/C across corners 对角距
A/F across flats 对边距
above stuffing上填料
accumulation of energy储能
accumulation积聚性
acme thread梯形(爱克姆)螺纹
across corner 对角距
across flat 对边距
actual size实际尺寸
acute angle 锐角
addendum 齿顶高
addendum circle 齿顶圆
admiralty metal含锡黄铜
affiliation从属性(关系)
ageing treatment时效处理
AL aluminum 铝
aligned sectional view旋转剖视图
allowance容差、加工余量
analytical method of line and plane线面分析法
analytical method of shape形体分析法
analyzable assembly分析装配图
ANG angle 角
angle bar or L-bar (beam)角钢
angle between axonometric axes轴间角
angular dimension 角度尺寸
angular gear人字齿轮
angular section斜剖面
angularity倾斜度
anneal退火
anti-clockwise逆时针方向的
arrow or arrowheads 箭头
asbestos packing石棉填料
ASM assembly 装配(图)、部件
assembly drawing number装配图图号
assembly drawings装配(组装)图
assembly for installation安装图
assembly parts装配组合零件
assembly sketches装配草图
auxiliary circle辅助圆
auxiliary plane辅助平面
auxiliary sectional view斜(辅助)剖视图 aligned and developed展开视图
AVG average 平均
axial coefficients of foreshortening轴向变形系数
axis line 轴线
axis of rotation转轴
axis轴线
axonometric axes轴测轴
axonometric drawing轴测图
axonometric projection轴测投影
B
BAB Babbitt 巴氏(轴承)合金
back (rear) view后(背)视图
bar杆
base line 基准线
base parts机座
base plane底平面
basic deviation基本偏差
basic hole基准孔
basic shaft基准轴
basic size基本尺寸
BB ball bearing 滚动轴承
bearing cover轴承盖
bearing set轴承座 bearing轴承
bell metal青铜(锡铜)合金
belt wheel带轮
bevel gear斜齿轮
BHN Brinell hardness number 布氏硬度值
bisector 平分线
blade spring板簧
blind hole 盲孔(不通的孔)
blind hole盲孔
blind threaded hole螺纹盲孔
blunt angle 钝角
body of revolution回转体
bolt joint螺栓连接
bolt螺栓
border 图框
border line 图框线
boring machine or boring镗床
boring镗孔
boss club凸台
bottom shell 下轴瓦
box箱体
brazing metal铜锌合金
bright washer平垫圈
Brinell hardness布氏(HB)硬度
broacher拉床、绞孔机
broaching拉床、扩孔机
broach拉光
broken line 断裂线
broken view (local view)局部视图
BRS brass 黄铜
BRZ bronze 青铜
burnish or polishing磨光
butterfly valve蝶形阀
buttress (screw) thread锯齿形(枪膛)螺纹
caliper卡尺(钳)
cap screw带帽螺钉(栓)
capital letters 大写字母
carburizing (carbon infiltration)渗碳
case hardened硬化、表面淬火
casting defect铸件缺陷
casting processes铸造工艺
casting铸造、铸件
castle nut内六角圆螺母
cavity空腔(穴)
CBORE counterbore 沉孔、埋头孔
center to center distance 中心距
centerline (central line) 中心线
center-to-center spacing中心距
central projection中心投影
CH HD cheese head 开槽圆柱头
CHAM chamfer 倒角
chamfer倒角
channel bar槽钢
characteristics of projection 投影特性
CHD checked (by) (由) …校对
check drawings校(核)图
cheese head圆柱头
Chinese characters 汉字
chrome plating镀铬
CI cast iron 铸铁
CIR circular 圆的
circular arc 圆弧、弧
circular pitch 齿距
circular pitch周节
circular runout圆跳动
CL or centerline 中心线
clamping夹紧
clearance fit间隙配合
clockwise顺时针方向的
CM centimeter 厘米
coarse pitch thread粗牙普通螺纹
coarse wheel粗砂轮加工
coating涂覆
coincidence (revolved) section重合断面
coincident point重影(合)点
color-hardening着色硬化、发蓝、发黑
combination solids组合体
commom tangent公切线
common axis公共轴线
common point 共有点
compass 圆规
component构件
compound sectional view复合剖视图
concave millstone凹面磨盘
concentric circle同心圆
concentricity and coaxiality同轴(心)度
conic (miter) gear圆锥(伞)齿轮
connecting bar连杆
construction line 作图线
contact surfaces接触表面
continuous straight thin line with zig zags 折线
continuous thick line 粗实线
continuous thin irregular line 波浪线
continuous thin line 细实线
contour arithmetic mean deviation轮廓算术平均偏差
contour element外形素线
conventional breaks折断规定画法
conventional representation规定画法
converge聚为一点
convex millstone凸面磨盘
coordinate axis坐标轴
COP copper 铜
copper plating镀铜
corrosion腐蚀
cotter (split) pin 开口(尾)销
counterbore hole 阶梯沉孔、埋头孔
counterboring tool 平底扩孔钻
counter-drill 阶梯钻
countersunk hole锥形沉孔、埋头孔
coupling or union连轴器
covering external thread套扣
CP circular pitch 周节
crank摇把
cross rib十字肋
cross section shape横断面形状
crossing line交叉线
crossing point交叉点
CRS (C to C) centers 中心距
CSK countersunk 锥孔、埋头孔
CU cubic 立方的
CU FT cubic foot 立方英尺
CU IN cubic inch 立方英寸
CU YD cubic yard 立方码
cube立方体
cuboid长方体
cup packing皮碗密封
curve template 曲线板
curved line of intersection曲交线
curved slot 曲线槽
cutting plane symbol剖切平面符号
cutting plane剖切平面
cut断面图
cycloidal gear摆线齿轮
CYL cylinder (cylindrical) 圆柱、圆柱体的
cylindricity圆柱度
D
dashed thin lines 虚线
datum feature基准要素
datum line基准线
datum plane基准面
datum point基准点
datum symbo基准代号 l
deburring去毛刺
dedendum circle 齿根圆
dedendum 齿根高
DEG or ? degree 度
delineator制图者
descriptive geometry 画法几何
descriptive geometry solution 图解法
design datum设计基准
DET DWG detail drawing 零件图
detail drawing零件图
detailing (an assembly drawing) (由装配图)拆画零件图
deviation尺寸偏差（偏差）
DIA or φ diameter 直径
DIAG diagonal 对角线(的)
diagonal line 对角线
diagram assembly drawing装配工作图
diagrammatic drawing示意图
diameter 直径
diamond knurling网纹滚花
dimension 尺码
dimension figure 尺寸数字
dimension form 尺寸格式
dimension line 尺寸线
dimension text 尺寸数值
dimension tolerance尺寸公差
dimetric drawing正二轴测图
dividers 分规
dome圆顶状
double-start thread双线螺纹
dowel pin 圆柱销
draft or draught起模斜度
drafting paper 绘图纸
drafting tape 胶带纸
drawing board 图板
drawing number图号
DRG drawing 制图、图样
drilling钻孔
drive gear主动齿轮
driven gear从动齿轮
driven shaft从动轴
DRN drawn (by) (由) …绘图
ductile cast iron球墨铸铁
dynamometry测力
E
edge line棱线
effective diameters弹簧中径
effective length有效长度
EI or ei 来自法文ecart inferieur 下偏差代号
elbow肘形弯管(头)
element circle素线圆
element symbol基本符号
elementary unit基本体
ellipse椭圆
elongated hole延长孔、拉伸孔
end cover端盖
end face端面
end point端点
engineering requirements技术要求
enlarged partial view局部放大图
enlargement scale 放大比例
EQUI SP or EQS equally spaced 均布
erasing shield 擦图片
ES or es 来自法文ecart superieur 上偏差代号
EXT external 外部的
extension line 尺寸界线
external (male) thread外(阳)螺纹
external diameter弹簧外径
external dimension外形尺寸
external tangency 外切
external thread lathing车外螺纹
external view外形视图
extreme position of moveable part 活动极限位置
extruding挤压
F
FAB fabricate 制造、装配
faucet旋塞、水龙头
feed spiral送料螺旋
felt ring毡圈
ferrous metal黑色金属
FIG. figure 附图、插图
FIL fillister 凹槽
file锉
filing margin 装订边
fill in填写
fillet铸造(内)圆角
fine boring精镗
fine broaching精拉
fine grinding精磨
fine milling精铣
fine pitch thread细牙普通螺纹
fine planning精刨
fine turning精车
finish all over全部加工
fissure裂纹
fit symbol配合代号
fit system配合制
fit配合
55? non sealing pipe thread 55?非密封管螺纹
55? sealing pipe thread 55?密封管螺纹
fixed body固定钳身
flange法兰盘、凸缘
flat bar扁钢
flat heads平顶
flat or plane平面
flatness平面度
follower从动(大齿)轮
font 字体
font cavity缩孔、铸口
forging锻压
fork拨叉
form error形状误差
forth quadrant第四象限
four quadrants四个象限
45? mitre line 45?斜线
free hand 徒手(画)
free height自由高度
frontal line正平线
frontal plane (or V-plane)正投影面
frontal plane正平面
frustum of a cone圆锥台
frustum of a cone截头圆锥
frustum of a pyramid棱锥台
FT or ′foot 英尺
full sectional view全剖视图
full size 原值比例
full thread全螺纹
functional dimensions功能尺寸
G
gasket密封垫(圈)
gauge calipers卡(量)规
gear box (case)齿轮箱
gear train齿轮传动
gear齿轮
general fit class配合种类
general-plane 一般位置平面
general-position line一般位置直线
generating circle母线圆
generator (generation) line母线
Geometric construction 几何作图
geometrical solid几何体
geometrical tolerance symbol形位公差符号
geometrical tolerance形状位置公差
GI galvanized iron 马口铁、镀锌铁
gib-head key钩头楔键
gland压盖
gland密封压盖
globe valve球阀
good-quality carbon steel优质碳素钢
grade 坡度
grade A and grade B of type one hexagon nutI 型六角螺母A级和B级
graduated scale 比例(分度)尺
graphical representation 图示法
Graphics 图学
GRD grind 磨削
grey cast iron灰口铸铁
grinding machine磨床
grinding研磨
grinding磨削
groove 凹槽、沟纹
guard valve安全阀
guide pin定位销
guide screw丝杠
H
half sectional view半剖视图
half view半视图
hand valve手压阀
hard casting白口铁
hard metal硬质合金
hardened and tempered调质的
harden淬火
hardness number硬度值
Hatching 剖面线
heat-treatment热处理
heavy lines 加深图线
heavy metal重金属
helical compression spring圆柱螺旋压缩弹簧
helical spring螺旋弹簧
helical spur gear斜齿圆柱齿轮
helical tension spring圆柱螺旋拉伸弹簧
herringbone gear人字形圆柱齿轮
HEX hexagon 六角(边)形
HEX HD hexagon head 六角头
hex nut六角螺母
hex slotted nut六角开槽螺母
hexagon head 六角头
hexagon head bolt六角头螺栓
hexagon head bolt六角头螺栓
hexagon socket cap screw内六角圆柱头螺钉
hexagon thin nut六角薄螺母
hidden edges 不可见轮廓线
high-carbon steel高碳钢
high-speed steel高速钢
hole-basis system of fits基孔制配合
horizontal (level) plane水平面
horizontal line水平线
horizontal projection plane (H-plane)水平投影面
hot-rolled steel热轧钢
HP horsepower 马力
H-perpendicular line铅垂线
H-perpendicular plane铅垂面
HR hour 小时
hub轮毂
hub轮毂、中心
hyperbola双曲线
I
hypotenuse直角三角形之斜边(弦)
I/D inside diameter 内径、内形尺寸
I-beam工字钢
imaginary line 假想线
IN or ″ inch 英寸
incenter 内(切圆)心
included angle夹角
inflexion拐点
ingot iron低碳钢(工业纯铁)
initial outline 初始轮廓线
inlet side入口端
inner race内圈
inside diameter内径
instruction book说明书
instrumental drawing 用仪器画的图
INT internal 内部的
interchangeability互换性
interference fit过盈配合
internal (female) thread内(阴)螺纹
internal (inside) caliper内卡尺(钳)
internal diameters弹簧内径
internal tangency 内切
internal thread lathing车内螺纹
interpenetration相贯
intersecting plane截平面
intersection line截交线
intersection of plane surfaces平面之交线
intersection of surfaces表面之交线
intersection point交点
Intersection相交
Intuitive illustrations直观图
involute gear渐开线齿轮
iron铁
ISO standards ISO国际标准
ISO=International Standardization Organization国际标准化组织
isometric drawing (diagram)正等轴测图
isometric projection正等测投影
isometric sectional view正等轴测剖视图
Italic font 斜体
J
jack千斤顶、起重器
jig body夹具体
junction surface结合面
K
key diagram原理草图
key joint键连接
key seat键座
key types键的型式
key way (slot)键槽
key键
knobbled (wrought) iron熟(锻)铁
knurling 滚花
knurling nut滚花螺帽
L
lamp plank钳口板
LAT lateral 侧(横)向的
lathe车床
LB pound 磅
lead distance导程
leader line 指引线
lead导程
leaf spring叶(薄)片弹簧
left hand-thread左旋螺纹
left-hand side (end) view左(端)视图
length of thread engagement螺纹旋合长度
letter 字母
lever arm长臂杠杆
LG long .length 长度、长的
LH left hand 左旋、左方向
light metal轻金属
limit size极限尺寸
limiting deviations极限偏差
limiting element转向轮廓素线
LIN linear 线性的、直线的
line segment 线段
line styles 线型
linearity直线性
lines in planes线在面上
L-iron角铁
local (broken-out) sectional view局部剖视图
location by dimension 定位尺寸
location dimension尺寸定位
lock nut防松螺母
lock screw锁紧螺钉
locking device锁紧装置
LONG longitude 经度(线)
long dashed dotted thin line 点画线
long dashed double dotted thin line 双点画线lower-case letters 小写字母
lower deviation下偏差
lower limit下限(值)
lubricant pump齿轮油泵
