CAMESA铠装电缆一览表
电缆型号
直径(英寸)
最高温度(华氏度)
拉伸强度 lbs.(磅)
建议工作负荷(磅)
空气中重量lbs/Kft
拉伸系数 ft/Kft/Kft
最小滑轮直径(英寸)
电阻值 Ohm/Kft
电容值 pf/ft
最大直流电压
铠装电阻 ohm/Kft
内铠数量及强度
外铠数量及强度
1N10RP
1/10
300
1,000
500
19
13.1
6
21
51
300
22
12/42
18/42
1N12RP
1/8
300
1,600
800
28
6.5
7
21
41
300
13
12/65
18/65
1N12RZ
1/8
500
1,600
800
30
6.5
7
21
48
300
13
12/65
18/65
1L18RP
3/16
300
4,000
2,000
66
3
14
9.4
53
1000
6
12/103
12/272
1L18RXZ
3/16
420
4,000
2,000
66
3
14
9.4
54
1000
6
12/103
12/272
1L18RZ
3/16
500
4,000
2,000
67
3
14
9.4
63
1000
6
12/103
12/272
1L18RTZ
3/16
500
4,000
2,000
67
3
14
9.4
56
1000
6
12/103
12/272
1K22PP
7/32
300 (149℃)
5,600
2,800
94
2.2
14
4
60
1200
4.3
15/125
15/272
1K22PXZ
7/32
420 (216℃)
5,600
2,800
96
2.2
14
4
61
1200
4.3
15/125
15/272
1K22PZ
7/32
500
5,600
2,800
97
2.2
14
4
69
1200
4.3
15/125
15/272
1K22PTZ
7/32
500
5,600
2800
96
2.2
14
4
58
1200
4.3
15/125
15/272
1K22SAZ-S75
7/32
300
4,800
2400
94
2.7
14
6.7
43
1200
16
15/113
15/246
1K22SAZ-36MO
7/32
400
5,200
2600
94
3.07
14
6.7
43
1200
22
15/125
15/272
1K22SAZ-MP35N
7/32
500
5,200
2600
100
2.4
14
6.7
43
1200
22
15/125
15/272
1N22PP
7/32
300
5,600
2800
94
2.5
13
4.1
58
1200
4.4
12/204
18/204
1N22PXZ
7/32
420
5,600
2800
95
2.5
13
4.1
59
1200
4.4
12/204
18/204
1N22PZ
7/32
500
5,600
2800
97
2.5
13
4.1
68
1200
4.4
12/204
18/204
1N22PTZ
7/32
500
5,200
2600
97
2.5
13
4.1
58
1200
4.4
12/204
18/204
1N22SAZ-S75
7/32
300
4,800
2400
96
2.9
13
6.7
43
1200
16
12/185
18/185
1N22SAZ-36MO
7/32
400
5,200
2600
94
3.07
13
6.7
43
1200
22
12/204
18/204
1N22SAZ-MP35N
7/32
500
5,200
2600
100
2.9
13
6.7
43
1200
22
12/204
18/204
1N25PP
1/4
300
7,000
3500
120
1.9
14
4.1
50
1200
3
12/272
18/272
1N25PXZ
1/4
420
7,000
3500
124
1.9
14
4.1
53
1200
3
12/272
18/272
1N25PTZ
1/4
500
7,000
3500
125
1.9
14
4.1
53
1200
3
12/272
18/272
1N25WTZ-S75
1/4
300
6,000
3000
127
2.3
14
4.4
53
1200
10
12/247
18/247
1N25WTZ-36Mo
1/4
400
6,400
3200
127
2.3
14
4.4
53
1200
10
12/260
18/260
1N29PP-HS
9/32
300
9,100
4550
153
1.6
16
3.5
54
1500
2.8
12/357
18/357
1N29PXZ-HS
9/32
420
9,100
4550
157
1.6
16
3.5
55
1500
2.8
12/357
18/357
1N29PTZ-HS
9/32
500
9,100
4550
159
1.6
16
3.5
54
1500
2.8
12/357
18/357
1N29PTZ-EHS
9/32
500
10,300
5150
159
1.55
16
3.5
54
1500
2.8
12/398
18/398
1N29WTZ-S75
9/32
300
8,200
4100
167
1.9
16
4
54
1500
10
12/308
18/308
1N32PP
5/16
300
11,600
5800
188
1.2
18
2.8
46
1500
2.1
12/420
18/420
1N32PXZ
5/16
420
11,600
5800
191
1.2
18
2.8
47
1500
2.1
12/420
18/420
1N32PTZ
5/16
500
11,600
5800
195
1.2
18
2.8
45
1500
2.1
12/420
18/420
1N32PTZ-LR-HS
5/16
500
11,750
5875
198
1.2
18
2.3
70
1500
2.1
12/442
18/442
1N32WTZ-S75
5/16
300
10,400
5200
197
1.2
18
3.3
45
1500
8
12/381
18/381
1N32WTZ-MP35
5/16
400
11,000
5500
197
1.2
18
3.3
45
1500
8
12/394
18/394
1N32WTZ-36MO
5/16
500
11,000
5500
206
1.2
18
3.3
45
1500
11
12/394
18/394
1N38PP
3/8
300
15,000
7500
258
1
21
2.8
39
1500
1.5
12/585
18/585
1N38PXZ
3/8
420
15,000
7500
264
1
21
2.8
39
1500
1.5
12/585
18/585
1N38PTZ
3/8
500
15,000
7500
269
1
21
2.8
39
1500
1.5
12/585
18/585
1N42PP
7/16
300
18,500
9250
320
0.7
24
2.8
35
1500
1.2
12/726
18/726
1N42PXZ
7/16
420
18,500
9250
328
0.7
24
2.8
35
1500
1.2
12/726
18/726
1N42PTZ
7/16
500
18,500
9250
334
0.7
24
2.8
35
1500
1.2
12/726
18/726
1N42PTZ-LR-HS
7/16
500
19,500
9750
334
0.7
24
2.3
37
1500
1.2
12/764
18/764
3H22RPP
7/32
300
4,700
2350
84
2.5
13
22.5
36
300
4.8
18/103
18/204
3H22RXZ
7/32
420
4,700
2350
84
2.5
13
22.5
35
300
4.8
18/103
18/204
3H22RTZ
7/32
500
4,700
2350
86
2.5
13
22.5
40
300
4.8
18/103
18/204
3H47PP
0.474
300
22,000
11000
369
0.61
26
6
44
1200
1.1
18/469
18/910
3H47PXZ
0.474
420
22,000
11000
376
0.61
26
6
45
1200
1.1
18/469
18/910
3H47PTZ
0.474
500
22,000
11000
382
0.61
26
6
43
1200
1.1
18/469
18/910
4H18RPP
3/16
300
3,100
1550
84
4.25
10
22.5
36
300
6.7
18/72
18/130
4H18RXZ
3/16
420
3,100
1550
84
4.25
10
22.5
35
300
6.7
18/72
18/130
4H18RTZ
3/16
500
3,100
1550
86
4.25
10
22.5
40
300
6.7
18/72
18/130
4H22RPP
7/32
300
4,700
2350
84
2.5
13
22.5
36
300
4.8
18/103
18/204
4H22RXZ
7/32
420
4,700
2350
84
2.5
13
22.5
36
300
4.8
18/103
18/204
4H22RTZ
7/32
500
4,700
2350
86
2.5
13
22.5
40
300
4.8
18/103
18/204
7H32RP
5/16
300
9,500
4750
183
1.8
18
15.8
55
1000
2.3
18/217
18/420
7H32RZ
5/16
500
9,500
4750
188
1.8
18
15.8
67
1000
2.3
18/217
18/420
7H38RP
3/8
300
13,000
6500
254
1.4
21
9.8
65
1000
1.8
18/298
18/585
7H38RZ
3/8
500
13,000
6500
261
1.4
21
9.8
77
1000
1.8
18/298
18/585
7H42RP
7/16
300
18,000
9000
310
0.75
24
9.8
53
1000
1.2
18/383
18/726
7H42RZ
7/16
500
18,000
9000
319
0.75
24
9.8
62
1000
1.2
18/383
18/726
7H42RTZ
7/16
500
18,000
9000
322
0.75
24
9.8
53
1000
1.2
18/383
18/726
7J46RP
15/32
300
18,000
9000
321
0.77
20
9.8
40
1200
1.3
24/323
24/520
7J46RXZ
15/32
420
18,000
9000
338
0.77
20
9.8
40
1200
1.3
24/323
24/520
7J46RTZ
15/32
500
18,000
9000
341
0.77
20
9.8
39
1200
1.3
24/323
24/520
7J46RP-HS
15/32
300
19,100
9550
321
0.77
20
9.8
40
1200
1.3
24/356
24/574
7J46RXZ-HS
15/32
420
19,100
9550
338
0.77
20
9.8
40
1200
1.3
24/356
24/574
7J46-RTZ-HS
15/32
500
19,100
9550
341
0.77
20
9.8
39
1200
1.3
24/356
24/574
7H47RP-HS
0.474
300
23,600
11800
377
0.61
26
9.8
46
1100
1.1
18/494
18/958
7H47RXZ-HS
0.474
420
23,600
11800
386
0.61
26
9.8
48
1100
1.1
18/494
18/958
7H47RTZ-HS
0.474
500
23,600
11800
392
0.61
26
9.8
46
1100
1.1
18/494
18/958
7Q49RTZZ-EHS
0.49
500
25,200
12600
405
0.6
25
9.8
26
1200
1
20/520
20/945
7Q52RP
0.521
300
26,000
13000
453
0.58
26
9.8
40
1200
0.85
16/726
20/910
7Q52RXZ
0.521
420
26,000
13000
459
0.58
26
9.8
40
1200
0.85
16/726
20/910
7Q52RTZ
0.521
500
26,000
13000
470
0.58
26
9.8
39
1200
0.85
16/726
20/910
华氏度 = 32 + 摄氏度 × 1.8
摄氏度 = (华氏度 - 32) ÷ 1.8
