1、金属切削 metal cutting 机床 machine tool 金属工艺学 technology of metals 刀具 cutter 摩擦 friction 联结 link 传动 drive/transmission 轴 shaft 弹性 elasticity 频率特性 frequency characteristic 误差 error 响应 response 定位 allocation 机床夹具 jig 动力学 dynamic 运动学 kinematic 静力学 static 分析力学 analyse mechanics 拉伸 pulling 压缩 hitting 剪切 shear
2、 扭转 twist 弯曲应力 bending stress 强度 intensity 三相交流电 three-phase AC 磁路 magnetic circles 变压器 transformer 异步电动机 asynchronous motor 几何形状 geometrical 精度 precision 正弦形的 sinusoid 交流电路 AC circuit 机械加工余量 machining allowance 变形力 deforming force 变形 deformation 应力 stress 硬度 rigidity 热处理 heat treatment 退火 anneal 正火
3、 normalizing 脱碳 decarburization 渗碳 carburization 电路 circuit 半导体元件 semiconductor element 反馈 feedback 发生器 generator 直流电源 DC electrical source 门电路 gate circuit 逻辑代数 logic algebra 外圆磨削 external grinding 内圆磨削 internal grinding 平面磨削 plane grinding 变速箱 gearbox 离合器 clutch 绞孔 fraising 绞刀 reamer 螺纹加工 thread p
4、rocessing 螺钉 screw 铣削 mill 铣刀 milling cutter 功率 power 工件 workpiece 齿轮加工 gear mechining 齿轮 gear 主运动 main movement 主运动方向 direction of main movement 进给方向 direction of feed 进给运动 feed movement 合成进给运动 resultant movement of feed 合成切削运动 resultant movement of cutting 合成切削运动方向 direction of resultant movement
5、of cutting 切削深度 cutting depth 前刀面 rake face 刀尖 nose of tool 前角 rake angle 机械专业词汇: hardenability 淬透性 carbide tool 硬质合金刀具 alloy tool steel 合金工具钢 alloyed cast iron 合金铸铁 carbon steel 碳素钢 carbon tool steel 碳素工具钢 cast iron 铸铁 cast steel 铸钢 die material 模具材料 high alloy steel 高合金钢 high carbon steel 高碳钢 low
6、alloy steel 低合金钢 low carbon steel 低碳钢 shock resistant tool steel 抗冲击工具钢 nodular graphite iron 球墨铸铁 malleable cast iron 可锻铸铁 mottled cast iron 麻口铸铁 hardenability curve 淬透性曲线 hardening capacity 淬硬性(硬化能力) hardness penetration diagram “U”形曲线 hardness profile 硬度分布(硬度梯度) heat treatment procedure 热处理规范 hea
7、t treatment installation 热处理设备 heat treatment furnace 热处理炉 heat treatment cycle 热处理工艺周期 heat time 加热时间 heat system 加热系统 heating up time 升温时间 heating curve 加热曲线 high temperature carburizing 高温渗碳 high temperature tempering 高温回火 isothermal annealing 等温退火 interrupted ageing treatment 分级时效处理 local heat t
8、reatment 局部热处理 overheated structure 过热组织 pack carburizing 固体渗碳 Oxynitrocarburizing 氧氮碳共渗 partial annealing 不完全退火 recrystallization temperature 再结晶温度 cutting part 切削部分 tool angle 刀具角度 tool back angle 背前角 tool back clearance 背后角 tool backlash movement (tool retracting) 退刀 tool back wedge angle 背楔角 too
9、l base clearance 基后角 tool cutting edge plane 切削平面 tool cutting edge angle 主偏角 tool grinding machine 工具磨床 tool geometrical rake 几何前角 tool nomal clearance(rake) 法后角(法前角) tool orthogonal clearance(rake, wedge) 后角(前角,楔角) locating device 定位装置 locating face 定位面 locating pin 定位销(挡料销) locating plate 定位板 loc
10、ating ring 定位圈 locating rule 定位尺 locating element 定位零件(定位要素) work hardening 加工硬化 internal cylindrical grinding machine 内圆磨床 internal cylindrical turing 内圆车削 internal force 内力 internal cylindrical grinding machine with vertica 立式内圆磨床 hole scraping (turning,milling, lapping) 刮孔(车孔,铣孔,研孔) hole grinding
11、 (slotting,honing, flanging) 磨孔(插孔,珩孔,翻孔) versatile grinding machine 多用磨床 versatile lathe 多用车床 vertical multi-tool lathe 立式多刀车床 precision milling machine 精密铣床 spot face 孔口平面 drill and countersink 定心钻,中心钻 counterbore cutter head 扩孔钻头 jig boring machine 坐标镗床 jig grinding machine 坐标磨床 jig and fixture 夹
12、具 fixture of gear cutting machine 齿轮加工机床夹具 fixture of milling machine 铣床夹具 fixture of grinding machine 磨床夹具 fixture of planing machine 刨床夹具 fixture of slotting machine 插床夹具 vacuum fixture 真空夹具 universal fixture (jig) 通用夹具 stationary fixture 固定夹具 standard fixture (jig) 标准夹具 pneumatic fixture (jig) 气动
13、夹具 open-side boring and milling machine 悬臂镗铣床 magnetic fixture (jig) 磁力夹具 locating device (face,element) 定位装置(面,元素) hydraulic fixture (jig) 液压夹具 slide gauge 游标卡尺 triple action press 三动压力机 tow point single action press 双点单动压力机 watch press 台式压力机 closed type single action crank press 闭式单动(曲柄)压力机 one po
14、int single action press 单点单动压力机 open-back inclinable press 开式双柱可倾压力机 four crank press 四曲柄压力机 stright side single action double crank press 闭式双点单动双曲柄压力机 single piece frame press 整体框架式压力机 rocker arm type press 摇臂式压力机 top drive sheet metal stamping automatic press 上传动板料冲压自动压力机 barrel surface 圆柱形表面 anti
15、flowback valve 反流阀 reciprocating-screw machine 往复螺旋注塑机 single-stage plunger 单级柱塞 shot chamber 注射室 curing temperature 固化温度 shot capacity 注射能力 plunger diameter 柱塞直径 sectional area of plunger 柱塞面积 hydraulic cylinder 液压缸 blanking die 冲裁模 blanking clearance, die clearance 冲裁间隙 blanking force 冲裁力 die,stam
16、ping and punching die 冲模 tonnage of press 压力机吨位 shut height of press machine 压力机闭合高度 clearance between punch and die 凹凸模间隙 tolerance of fit 配合公差 shearing force diagram 剪力图 peak die load 模具最大负荷 center of die, center of load 压力中心 clamping force (element, device, piston) 夹紧力(件,装置,活塞) clamp plate (ring)
17、 压板(夹紧环) shearing force (plane) 剪切力(平面) side clearance angle 侧隙角 side locating face 侧定位面 side-push plate 侧压板 shuttle table 移动工作台 matrix plate 凹模固定板 material removal rate 材料切除率 sheet matal 板料 blanking die 冲裁模 assembling die 复合冲模,装配用模具 compound blank and pierce dies 落料冲孔模 shaving die 切边模,修边模 shankless
18、 die 无柄模具 scrapless progressive die 无废料连续模 return-blank type blanking die 顶出式落料模 expanding die 胀形模,扩管模 die for special purpose 专用模 cavity plate (block) 凹模 bend ability 可弯性 bend arc 弯曲弧 bending angle (line) 弯曲角(线) bending brake (bending machine) 弯板机,拆弯机 bending fatigue 弯曲疲劳 bending radius 弯曲半径 minimu
19、m bending radius 最小弯曲半径 bending operation 弯曲工序 air-bend die 自由弯曲模 bending moment diagram 弯矩图 blank length of bend 弯曲件展开长度 relative bending radius 相对弯曲半径 bending equipment for plastics 塑料折弯设备 drawing machine 拉拔机 drawing numbers 拉伸次数 drawing ratio (coefficient,force,speed) 拉伸比(系数,力,速度) foamed (cellula
20、r) plastic 泡沫塑料 Thermoplastic 热塑性塑料 plastic industry 塑料(工业)行业 blow molding die for plastics 塑料吹模机 standard die components for plastics 塑料模具标准化零部件 thermoforming machine for plastics 塑料热成型机 foaming mold for plastics 泡沫塑料模型 plastic molding press 塑料制品成型压力机 other plastics converting machine 其它塑料加工机械 comp
21、ression molding machine 压塑机 extruder double-screw for plastics 塑料加工用双螺杆挤压机 extruder single-screw for plastics 塑料加工用单螺杆挤压机 laminating machine 层压机 parting surface 分型面 transfer mold 压注模(也称传递模) flash-type mold 溢出式压缩模 portable transfer mold 移动式压注模 mold for plastics 塑料成型模具(简称塑料模) mold for thermoplastics 热
22、塑性塑料模 Draft 脱模斜度 transfer mold 传递模 injection mold for thermoplastics 热塑性塑料注射模 portable transfer mold 移动式传递模 fixed transfer mold 固定式传递模 insulated runner mold 绝热流道模 warm runner mold 温流道模 ring gate 环形浇口 pin-point gate 点浇口 edge gate 侧浇口 submarine gate, tunnel gate 潜伏浇口 runner plate 流道板 spreader 分流锥 warm
23、 runner plate 温流道板 stationary mold, fixed half, fixed die, cover die 定模 moving die, movable mold, moving half 动模 sprue gating 中心浇口,浇道浇口 die-casting die 压力铸造模具(简称压铸模) fixed clamping plate 定模底板 moving clamping plate 动模底板 support plate, backing plate 支承板 movable core 活动型芯 baffle 导流块 sprue spreader 分流锥(
24、分流器) ejector pin (plate) 推杆(板) ejector pin retaining plate 推杆固定板 gate 内浇口 air vent 排气槽 parting line 分型面 feed (gating, runner) system 浇注系统 pouring temperature (rate, time) 浇注温度(速度,时间) sprue base (bush, gate, puller) 直浇道窝(浇口套,直接浇口,拉料杆) final forging temperature 终锻温度 finishing temperature 终锻温度 initial
25、forging temperature 始锻温度 flat die hammer 自由锻锤 forge furnace 锻炉 forge ratio (forge reduction) 锻造比 forging crankpress 锻造用曲柄压力机 forging die (die steel, drawing) 锻模(锻模钢,锻件图) forging line (load, practice) 锻造生产线(负荷,工艺) forging plane (plant) 锻造面(厂) forging pressure (process, range) 锻造力(工艺,范围) hammer forgin
26、g die 锤锻模 forging heat-treatment 锻件热处理 forging temperature interval 锻造温度范围 forging tolerance 锻件公差 hot forging drawing 热锻件图 chip formation 成型切削 chip load (force) 切削力 drilling and reaming 钻孔和铰孔 taper turning 锥度车削 external threading 外螺纹车削 chuck handle 夹头扳手,夹头钥匙 combination chuck 复动夹头 shaper and planer
27、牛头刨床和龙门刨床 slotting machine 插床 rotary-type bushing 旋转衬(钻)套 underlying metal 底层金属 perforated electrode 多孔电极 electro-chemical machining 电化学加工 form electromachining 电加工成形面 electric machining 电加工 salt bath electrode furnace 电极盐浴炉 electrolytic forming machine 电解成形机 electrochemical machining 电解加工 electroch
28、emical machining tool 电解加工机床 electrolytic universal tool and cutter grinder 电解万能工具磨床 electrolytic heat treatment 电解液热处理 electrohydraulic forming 电液成形 electrolytic marking machine 电解刻印机 electrolytic surface grinder 电解平面磨 spark erosion machining 电火花加工法 electrical discharge machining (EDM) 电火花加工 electr
29、odischarge cutting machine 电火花切割机 electrical discharge machine 电火花加工机床 electrical spark-erosion perforation 电火花打孔 electrode contact surface 电极接触面 electrical discharge forming 电火花成形机 laser cutting machine 激光切割机 electron beam cutting machine 电子束切割机 cavity sinking EDM machines 型腔电火花加工机床 travelling-wire
30、 EDM machine 线电极电火花加工机床 electro-discharge machine tool 电火花加工机床 electron beam machining (EBM) 电子束加工 electron beam machine tool 电子束加工机床 form electromachining 电加工成形面 tiny hole spark-erosion grinding machine 电火花小孔磨床 spark-erosion cutting with a wire 电火花线切割 wire cut electric discharge machine 电火花线切割机 enc
31、oded transducer 编码传感器 compensator 补偿器 incremental measuring system 增量测量系统 analog control 模拟控制 assembly language 汇编语言 data processing system 数据处理系统 graphic data processing 图形处理 linear (circle) interpolator 线形(圆形)插补器 DNC-direct numerical control 直接数字控制 CNC-computer numerical control 计算机数字控制 DPU-Data P
32、rocessing Unit 数控处理单元 DLU-Data Loops Unit 数据循环单元 cutter saddle 刀架 cylinder saddle 鞍形气缸座 a safety loop 保险圈 a wire loop 钢丝圈 loop a line 环路法连接线路 horizontal spindle 轴式 vertical spindle 立轴式 travelling-column 行程立柱 feedback unit 反馈单元 machining center 加工中心 tool-storage 刀具存贮 ball screw 滚珠丝杠 tool changer 刀库 m
33、achine control unit (MCU) 机床控制单元 flexible machining system 柔性制造系统 disk operating system (DOS) 磁盘操作系统 Microsoft dish operating ssytem (MS-DOS) 微软磁盘操作系统 program and data files 程序和数据文件 internal and external command 内部和外部文件 format a diskette 磁盘格式化 diskcopy command 磁盘拷贝命令 erase (deletion) command 删除命令 cr
34、eate (change, remove) directory 建立(改变,移动)目录 hard disk drive (HDD) 硬盘驱动器 hard (soft) disk 硬(软)盘 standard keyboard 标准键盘 color display 彩色显示 printer operating procedures 打印机操作程序 application window 应用程序窗口 batch file 批处理文件 control (main,system) menu 控制(主,系统)菜单 configuration system file 系统配置文件 FMS (flexibl
35、e manufacturing system) 柔性制造系统 CNC (computer numerical control) 计算机数字控制 revised feed signal 反进给信号 default selection mode 默认选择模式 MCU (machine control unit) 控制加工单元 ACS (adaptive control system) 自动补偿系统 CRT (cathode-ray tube) 显像管 process planning 制定工艺过程 CIM (computer integrated manufacturing) 计算机集成制造 ve
36、rtical stroke 垂直行程 system variable 系统变量 accurate die casting 精密压铸 air bend die 悬空弯曲模具 blank through dies 漏件式下了模 calendering 压延成形 center gated mold 中心浇口式模具 cold chamber die casting 冷室压铸 compacting molding 粉末压出成形 double stack mold 双层模具 duplicated cavity plate 复板模 encapsulation molding 注入成形 expander di
37、e 扩径模 family mold 成套制品模具 fantail die 扇尾形模具 fantail die 鱼尾形模具 f;ash mold 溢料式模具 flash mold 溢料式模具 flange bending die 弯缘模具 flang trim die 整缘磨具 flash trimming die 整缘磨具 flat edge teim die 水平整缘磨具 foam frming 发泡成形 gang die 成排模具 gravity casting 重力铸造 sand mold casting 砂模铸造 sectional die 对合模具 shaper 定型模具 singe
38、 cavity mold 单腔模具 squeeze casting die 高压铸造 squeezing casting die 挤压模 swaging 挤锻 tandem die 串列模具 shree plates mold 三板式模具 transfer molding 传送成形 universal mold 通用模具 warn foring 温锻 air vent valve 通气阀 anchir pin 锚梢 angular cams 角凸轮 angular pin 交梢(倾斜梢) baffle 调节阻板 baffle plate 折流档板 ball button 球塞套 ball pl
39、unger 定位球塞 binder plate 压板 ball silder 球塞滑块 binder plate 压板 blank holder 防皱压板 blanking punch 下料冲头 bottom board 浇注底板 bottom plate 下固定板 bracket 托架 casting ladle 浇注包 casting lug 铸耳 cavity 模穴(模仁/模腔) cavity adaptor plate 固定侧安装板 cavityplate 模仁板 cavity retainer plate 模穴托板 clamping block 锁定块 cooling manifol
40、d 冷却歧管 core adaptor plate 可动侧安装板 core plate 心型板 core push back spring 心型回位弹簧 diaphragm gate 盘形浇口 die approach 模头料道 die clamper 夹模器 die fastener 模具固定用零件 die plate 冲模板 direct gate 直接浇口 draft 拔模锥度 draw bead 张力调整杆 drive bearing 传动轴承 ejector pad 顶出垫 ejector plate 顶出板 ejector valve 顶出阀 calendaring molding
41、 压延成形 powder metal forging 粉末锻造 rotary forging 回转锻造 rotational molding 离心成形 shell casting 壳模铸造 foam forming 发泡成形 hot chamber die casting 热室压铸 warm forging 温锻 investment casting 精密铸造 matched die method 对模成形法 laminating method 被覆淋膜成形 low pressure casting 低压铸造 lost wax casting 脱腊铸造 matched mould therma
42、l forming 对模热成形模 landed plunger mold 有肩柱塞式模具 landed positive mold 有肩全压式模具 loading shoe mold 料套式模具 center-gated mold 中心浇口式模具 loose detail mold 活零件模具 manifold die 分歧管模具 modular mold 组合式模具 multi-cavity mold 多模穴模具 multi-gate mold 复式浇口模具 palletizing die 叠层模 plaster mold 石膏模 fishtail die 鱼尾形模具 protable mo
43、ld 手提式模具 lancing die 切口模 raising(embossing) 压花起伏成形 re-entrant mold 倒角式模具 single cavity mold 单腔模具 three plates mold 三片式模具 air vent vale 通气阀 anchor pin 锚梢 ball slider 球塞滑块 cooling spiral 螺旋冷却栓 ejection pad 顶出衬垫 ejector leader busher 顶出导梢衬套 film gate 薄膜形浇口 finish machined plate 角形模板 finish machined rou
44、nd plate 圆形模板 fixed bolster plate 固定侧模板 flanged pin 带凸缘销 flash gate 毛边形浇口 flask 上箱 floating punch 浮动冲头 gate land 浇口面 guide plate 导板 guide rail 导轨 head punch 顶镦冲头 headless punch 直柄沖头 heavily tapered solid 整体模蕊盒 impact damper 缓冲器 injection ram 压射柱塞 inlay busher 嵌入衬套 knockout bar 脱模杵 land 合模平坦面 land ar
45、ea 合模面 locating center punch 定位中心冲头 locating pilot pin 定位导梢 locking plate 定位板 making die 打印冲子 manifold block 歧管档块 master plate 靠模样板 match plate 分型板 mold base 塑胶模座 mold clamp 铸模紧固夹 mold platen 模用板 moving bolster plate 可动侧模板 one piece casting 整体铸件 parallel block 平行垫块 paring line 分模线 parting lock set 合
46、模定位器 pass guide 穴型导板 peened head punch 镶入式冲头 pin gate 针尖浇口 plate 衬板 rack 机架 rapping rod 起模杆 retainer pin 嵌件梢 retainer plate 托料板 slag riser 冒渣口 spacer block 间隔块 spacer ring 间隔环 square key 方键 square nut 方螺帽 square thread 方螺纹 stop collar 限位套 straight pin 圆柱销 stripper plate 剥料板 submarine gate 潜入式浇口 supp
47、ort pillar 支撑支柱/頂出支柱 supporting plate 扥板 tab gate 辅助浇口 taper key 推拔键 taper pin 拔锥梢/锥形梢 three start screw 三条螺纹 tie bar 拉杵 tunnel gate 隧道形浇口 wortle plate 拉丝模板 3D coordinate measurement 三次元量床 boring machine 搪孔机 cnc milling machine CNC铣床 contouring machine 轮廓锯床 copy grinding machine 仿形磨床 copy lathe 仿形车床
48、 copy milling machine 仿形铣床 copy shaping machine 仿形铇床 cylindrical grinding machine 外圆磨床 die spotting machine 合模机 drilling machine 钻孔机 engraving machine 雕刻机 engraving E.D.M. 雕模放置加工机 form grinding machine 成形磨床 graphite machine 石墨加工机 horizontal boring machine 卧式搪孔机 horizontal machine center 臥式加工制造中心 int
49、ernal cylindrical machine 內圆磨床 lap machine 研磨机 machine center 加工制造中心 NC drilling machine NC钻床 NC grinding machine NC磨床 NC lathe NC车床 NC programming system NC程式制作系统 planer 龙门铇床 profile grinding machine 投影磨床 radial drilling machine 旋臂钻床 surface grinder 平面磨床 try machine 试模机 turret lathe 转塔车床 universal tool grinding machine 万能工具磨床 vertical machine center 立式加工制造中心 autocollimator 自动准直机 bench comparator 比长仪 block gauge 块规 calibration 校准 caliper gauge 卡规 check gauge 校对规 clearance gauge 间隙规 comparator 比测仪 cylinder square 圆筒直尺 depth gauge 测深规 dial indicator 针盘指示表 dial snap gauge 卡规 digital micromete
