3GPP TS 36.213 V8.6.0 (2009-03)
Technical Specification
3rd Generation Partnership Project;
Technical Specification Group Radio Access Network;
Evolved Universal Terrestrial Radio Access (E-UTRA);
Physical layer procedures
(Release 8)
The present document has been developed within the 3rd Generation Partnership Project (3GPP TM) and may be further elaborated for the purposes of 3GPP.
The present document has not been subject to any approval process by the 3GPP Organisational Partners and shall not be implemented.
This Specification is provided for future development work within 3GPP only. The Organisational Partners accept no liability for any use of this Specification.
Specifications and reports for implementation of the 3GPP TM system should be obtained via the 3GPP Organisational Partners’ Publications Offices.
3GPP TS 36.213 V8.6.0 (2009-03)
72
Release 8
Keywords
UMTS, radio, layer 1
3GPP
Postal address
3GPP support office address
650 Route des Lucioles – Sophia Antipolis
Valbonne – France
Tel.: +33 4 92 94 42 00 Fax: +33 4 93 65 47 16
Internet
http://www.3gpp.org
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.
© 2009, 3GPP Organizational Partners (ARIB, ATIS, CCSA, ETSI, TTA, TTC).
All rights reserved.
UMTS™ is a Trade Mark of ETSI registered for the benefit of its members
3GPP™ is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners
LTE™ is a Trade Mark of ETSI currently being registered for the benefit of its Members and of the 3GPP Organizational Partners
GSM® and the GSM logo are registered and owned by the GSM Association
Contents
Foreword 5
1 Scope 6
2 References 6
3 Definitions, symbols, and abbreviations 7
3.1 Symbols 7
3.2 Abbreviations 7
4 Synchronisation procedures 8
4.1 Cell search 8
4.2 Timing synchronisation 8
4.2.1 Radio link monitoring 8
4.2.2 Inter-cell synchronisation 8
4.2.3 Transmission timing adjustments 8
5 Power control 9
5.1 Uplink power control 9
5.1.1 Physical uplink shared channel 9
5.1.1.1 UE behaviour 9
5.1.1.2 Power headroom 12
5.1.2 Physical uplink control channel 12
5.1.2.1 UE behaviour 12
5.1.3 Sounding Reference Symbol 14
5.1.3.1 UE behaviour 14
5.2 Downlink power allocation 15
5.2.1 eNodeB Relative Narrowband TX Power restrictions 16
6 Random access procedure 16
6.1 Physical non-synchronized random access procedure 16
6.1.1 Timing 17
6.2 Random Access Response Grant 17
7 Physical downlink shared channel related procedures 18
7.1 UE procedure for receiving the physical downlink shared channel 19
7.1.1 Single-antenna port scheme 21
7.1.2 Transmit diversity scheme 21
7.1.3 Large delay CDD scheme 22
7.1.4 Closed-loop spatial multiplexing scheme 22
7.1.5 Multi-user MIMO scheme 22
7.1.6 Resource allocation 22
7.1.6.1 Resource allocation type 0 22
7.1.6.2 Resource allocation type 1 23
7.1.6.3 Resource allocation type 2 24
7.1.7 Modulation order and transport block size determination 25
7.1.7.1 Modulation order determination 25
7.1.7.2 Transport block size determination 26
7.1.7.2.1 Transport blocks not mapped to two-layer spatial multiplexing 27
7.1.7.2.2 Transport blocks mapped to two-layer spatial multiplexing 32
7.1.7.2.3 Transport blocks mapped for DCI Format 1C 33
7.1.7.3 Redundancy Version determination for Format 1C 33
7.2 UE procedure for reporting channel quality indication (CQI), precoding matrix indicator (PMI) and rank indication (RI) 33
7.2.1 Aperiodic CQI/PMI/RI Reporting using PUSCH 36
7.2.2 Periodic CQI/PMI/RI Reporting using PUCCH 40
7.2.3 Channel quality indicator (CQI) definition 46
7.2.4 Precoding Matrix Indicator (PMI) definition 48
7.3 UE procedure for reporting ACK/NACK 49
8 Physical uplink shared channel related procedures 52
8.1 Resource Allocation for PDCCH DCI Format 0 54
8.2 UE sounding procedure 55
8.3 UE ACK/NACK procedure 57
8.4 UE PUSCH Hopping procedure 58
8.4.1 Type 1 PUSCH Hopping 59
8.4.2 Type 2 PUSCH Hopping 59
8.5 UE Reference Symbol procedure 60
8.6 Modulation order, redundancy version and transport block size determination 60
8.6.1 Modulation order and redundancy version determination 60
8.6.2 Transport block size determination 61
8.6.3 Control information MCS offset determination 61
8.7 UE Transmit Antenna Selection 63
9 Physical downlink control channel procedures 64
9.1 UE procedure for determining physical downlink control channel assignment 64
9.1.1 PDCCH Assignment Procedure 64
9.1.2 PHICH Assignment Procedure 65
9.2 PDCCH validation for semi-persistent scheduling 66
10 Physical uplink control channel procedures 67
10.1 UE procedure for determining physical uplink control channel assignment 67
10.2 Uplink ACK/NACK timing 72
Annex A (informative): Change history 74
Foreword
This Technical Specification (TS) has been produced by the 3rd Generation Partnership Project (3GPP).
The contents of the present document are subject to continuing work within the TSG and may change following formal TSG approval. Should the TSG modify the contents of this present document, it will be re-released by the TSG with an identifying change of release date and an increase in version number as follows:
Version x.y.z
where:
x the first digit:
1 presented to TSG for information;
2 presented to TSG for approval;
3 or greater indicates TSG approved document under change control.
y the second digit is incremented for all changes of substance, i.e. technical enhancements, corrections, updates, etc.
z the third digit is incremented when editorial only changes have been incorporated in the document.
1 Scope
The present document specifies and establishes the characteristics of the physicals layer procedures in the FDD and TDD modes of E-UTRA.
2 References
The following documents contain provisions which, through reference in this text, constitute provisions of the present document.
· References are either specific (identified by date of publication, edition number, version number, etc.) or non specific.
· For a specific reference, subsequent revisions do not apply.
· For a non-specific reference, the latest version applies. In the case of a reference to a 3GPP document (including a GSM document), a non-specific reference implicitly refers to the latest version of that document in the same Release as the present document.
[1] 3GPP TR 21.905: “Vocabulary for 3GPP Specifications”
[2] 3GPP TS 36.201: “Evolved Universal Terrestrial Radio Access (E-UTRA); Physical Layer – General Description”
[3] 3GPP TS 36.211: “Evolved Universal Terrestrial Radio Access (E-UTRA); Physical channels and modulation”
[4] 3GPP TS 36.212: “Evolved Universal Terrestrial Radio Access (E-UTRA); Multiplexing and channel coding”
[5] 3GPP TS 36.214: “Evolved Universal Terrestrial Radio Access (E-UTRA); Physical layer – Measurements”
[6] 3GPP TS 36.101: “Evolved Universal Terrestrial Radio Access (E-UTRA); User Equipment (UE) radio transmission and reception”
[7] 3GPP TS 36.104: “Evolved Universal Terrestrial Radio Access (E-UTRA); Base Station (BS) radio transmission and reception”
[8] 3GPP TS36.321, “Evolved Universal Terrestrial Radio Access (E-UTRA); Medium Access Control (MAC) protocol specification”
[9] 3GPP TS36.423, “Evolved Universal Terrestrial Radio Access (E-UTRA); X2 Application Protocol (X2AP)”
[10] 3GPP TS36.133, “Evolved Universal Terrestrial Radio Access (E-UTRA); Requirements for support of radio resource management”
[11] 3GPP TS36.331, “Evolved Universal Terrestrial Radio Access (E-UTRA); Radio Resource Control (RRC) protocol specification”
3 Definitions, symbols, and abbreviations
3.1 Symbols
For the purposes of the present document, the following symbols apply:
Downlink bandwidth configuration, expressed in units of as defined in [3]
Uplink bandwidth configuration, expressed in units of as defined in [3]
Number of SC-FDMA symbols in an uplink slot as defined in [3]
Resource block size in the frequency domain, expressed as a number of subcarriers as defined in [3]
Basic time unit as defined in [3]
3.2 Abbreviations
For the purposes of the present document, the following abbreviations apply.
ACK Acknowledgement
BCH Broadcast Channel
CCE Control Channel Element
CQI Channel Quality Indicator
CRC Cyclic Redundancy Check
DAI Downlink Assignment Index
DL Downlink
DTX Discontinuous Transmission
EPRE Energy Per Resource Element
MCS Modulation and Coding Scheme
NACK Negative Acknowledgement
PBCH Physical Broadcast Channel
PCFICH Physical Control Format Indicator Channel
PDCCH Physical Downlink Control Channel
PDSCH Physical Downlink Shared Channel
PHICH Physical Hybrid ARQ Indicator Channel
PRACH Physical Random Access Channel
PRB Physical Resource Block
PUCCH Physical Uplink Control Channel
PUSCH Physical Uplink Shared Channel
QoS Quality of Service
RBG Resource Block Group
RE Resource Element
RPF Repetition Factor
RS Reference Signal
SIR Signal-to-Interference Ratio
SINR Signal to Interference plus Noise Ratio
SPS C-RNTI Semi-Persistent Scheduling C-RNTI
SRS Sounding Reference Symbol
TA Time alignment
TTI Transmission Time Interval
UE User Equipment
UL Uplink
UL-SCH Uplink Shared Channel
VRB Virtual Resource Block
4 同步过程
4.1 小区搜索
小区搜索是指UE在小区中获取时间和频率同步并检测小区物理层Cell ID的过程。E-UTRA小区搜索支持包含6个以上资源块的传输带宽范围内的搜索。
通过主同步信号和辅同步信号的发送实现下行链路的小区搜索。
4.2 时间同步
4.2.1 无线链路监测
UE应该监测服务小区无线链路的质量，因为UE要把探测到的同步状况传给高层，
在非DRX（Discontinuous Receptio，省电模式）模式操作，UE的物理层在每个无线帧都要检测无线链路质量，并通过前一时间段[200ms]周期测得 ，这个无线链路质量的检测依赖于门限Qout and Qin（在[10]相关测试中被隐含定义）。
在DRX模式操作，UE的物理层至少每个DRX阶段都要检测无线链路质量，并通过之前的周期[10中定义]测得。这个无线链路质量的检测依赖于门限Qout and Qin（在[10]相关测试中被隐含定义）。
UE的物理层 在检测无线链路质量的无线帧中指示同步情况并上报给高层：当无线链路质量比门限值Qout差时，指示为失同步；当无线链路质量好于Qin时，指示为同步。
4.2.2 小区间同步
例如，用于有多播物理信道的小区。
4.2.3 传输定时校正
收到定时提前命令后，UE应该调整PUCCH/PUSCH/SRS的上行发送时间。定时提前命令表示为16的整数倍,它和当前上行时间相关。随机接入前导的起始时间在211中设定。
随机接入响应中，时间提前命令TA,为11bit，通过索引值TA = 0, 1, 2, ..., 1282,来表示NTA值，其中时间序列的数据由NTA = TA ´16给出。NTA在[3]中定义。
其它情况下，时间提前命令TA,为6bit，指示当前NTA值相对于新的NTA值NTA,new,的校正，其中索引值TA = 0, 1, 2,..., 63, NTA,new = NTA,old + (TA -31)´16.这里，NTA 值的校正是通过一个正的或负的数据，根据给出的数据分别来指示上行传输定时的时间提前或延迟
子帧n上接收到时间提前命令，相应的定时校正从子帧n+6的开始来进行。当由于时间校正，UE的子帧n和n+1中传输的上行PUCCH/PUSCH/SRS有重叠，UE应传输完整的子帧n，而不传输子帧n+6的重叠部分。
如果接收到的下行定时发生改变，没有[10]中所提到的时间提前要求，上行定时校正不再补偿或只是部分补偿,那么UE随之改变NTA。
5 功率控制
下行功率控制决定单位资源元素上的功率值，可见是在频域进行功率分配再进行时域加CP，同时功率分配是进行在子载波上，是对各个复信号上的幅度的调整。上行功率控制决定所传输的DFT-SOFDM符号上的功率值。
5.1 上行功率控制
上行功率控制控制着不同物理信道的发送功率值。
关于小区级的过载指示 (OI) 高干扰指示 (HII) 的干扰协调定义在参考文献[9]。
5.1.1 上行物理共享信道
5.1.1.1 UE行为
每个子帧i 的物理上行信道PUSCH的发送功率 设定计算如下：
[dBm]
其中：
· ：UE最大发送功率，23dBm左右，见 [6]的6.2.2节。
· ：在子帧i中PUSCH所占的带宽，单位是资源块RB。
· ： = +。高层决定j的取值，j=0 时，对应半静态授权的PUSCH传输或重传；j=1时，对应动态授权的PUSCH传输或重传；j=2时，对应随机接入响应授权的PUSCH传输或重传，此时， ，其中，和由高层信令配置；
· 当j =0 或1时, 是一个3bit高层配置的小区级参数； 当 j=2时, ；（部分功率补偿因子）
· PL ：下行路损估计值。通过下式计算出，PL = referenceSignalPower – higher layer filtered RSRP。其中 referenceSignalPower 由高层配置，RSRP 在参考文档[5]中定义，而higher layer filter在[11]中配置。
· ：公式如下，。其中或者，其配置情况由高层配置用户级参数deltaMCS-Enabled决定。
o 当ＰＵＳＣＨ中只有控制数据时，；其它情况等于 。
§ 等于码块数, 等于第个码块的大小，等于加上CRC位的ＣＱＩ比特数，等于资源元素由公式得出。其中, 和 在参考文档[4]给出，并且, 和在ＰＤＣＣＨ初始化的时候获得。
o 当ＰＵＳＣＨ中只有控制数据时 ；其它情况等于。
· ：用户级参数，对应于DCI0和联合编码DCI3/3A的PDCCHTPC命令。DCI0使用C-RNTI加扰CRC，DCI3/3A使用TPC-PUSCH-RNTI加扰CRC。当前子帧PUSCH的功率调整值等于，定义如下：
o 当累积修正Accumulation-enabled 使能时，或者在DCI0调整情况下
§ 其中是在DCI0或DCI3/3A传下来的信令TPC，来自对应PDCCH的子帧为 , 而且是最初的累积值。
§ 的值定义如下:
· 在FDD情况下,= 4
· 在TDD UL/DL配比 1-6时, 由表Table 5.1.1.1-1给出。
· 在TDD UL/DL 配比 0时
o 如果子帧2和7的PUSCH是PDCCH的DCI0调度的，且DCI0中的UL index域高位设为1时, = 7。
o 其它PUSCH传输情况时, 由表5.1.1.1-1设置。
· 除非处在DRX状态，UE会不断地在每个子帧检测DCI0和DCI3/3A分别使用C-RNTI和TPC-PUSCH-RNTI。
§ 如果DCI0和DCI3/3A都被检测成功，UE会选择DCI0的TPC用作。
§ 如果没有TPC命名下发或者处在DRX状态下以及没有上行子帧时，。
§ 的取值单位为dB，其和DCI0中TPC取值对应关系见表5.1.1.1-2。
§ 的取值单位为dB，其和DCI3/3A中TPC取值对应关系见表5.1.1.1-2或者表5.1.1.1-3，具体用户的TPC由高层配置的TPC-Index决定。
§ 如果UE到达最大发送功率时，正的功率修正值TPC不再有效。
§ 如果UE到达最小发送功率时，负的功率修正值TPC不再有效。
§ UE应该在以下情况复位累加值：
· 当绝对功率修正值TPC命令收到时；
· 当收到信令时；
· 当UE收到随机接入响应消息时；
o 当累积修正Accumulation-enabled 不使能时，
§ 其中由上ＤＣＩ０传送下来ＴＰＣ决定
§ 的值等于：
· 在 FDD情况下,= 4
· 在 TDD UL/DL配比1-6时, 由表5.1.1.1-1决定。
· 在TDD UL/DL配比0
o 如果子帧2和7的PUSCH是PDCCH的DCI0调度的，且DCI0中的UL index域高位设为1时, = 7。
o 其它PUSCH传输情况时, 由表5.1.1.1-1设置。
§ 的取值单位为dB，其和DCI0中TPC取值对应关系见表5.1.1.1-2。
§ 当子帧DCI0没有检测到、处在DRX状态以及TDD制式下无上行子帧时：。
o 在累积修正和绝对值修正情况下，都须满足下面设定：
§ 如果收到高层命令，
·
§ 否则
·
o 其中 是随机接入响应专有的TPC命令，参见6.2节，
o 来自高层，对应总功率放大范围，从第一个preamble到最后一个preamble结束。
Table 5.1.1.1-1 for TDD configuration 0-6
TDD UL/DL
Configuration
subframe number i
0
1
2
3
4
5
6
7
8
9
0
-
-
6
7
4
-
-
6
7
4
1
-
-
6
4
-
-
-
6
4
-
2
-
-
4
-
-
-
-
4
-
-
3
-
-
4
4
4
-
-
-
-
-
4
-
-
4
4
-
-
-
-
-
-
5
-
-
4
-
-
-
-
-
-
-
6
-
-
7
7
5
-
-
7
7
-
Table 5.1.1.1-2: Mapping of TPC Command Field in DCI format 0/3 to absolute and accumulated values.
TPC Command Field in
DCI format 0/3
Accumulated [dB]
Absolute [dB] only DCI format 0
0
-1
-4
1
0
-1
2
1
1
3
3
4
Table 5.1.1.1-3: Mapping of TPC Command Field in DCI format 3A to values.
TPC Command Field in
DCI format 3A
[dB]
0
-1
1
1
5.1.1.2 功率池
UE功率池定义如下：
[dB]
其中, , , , , PL, and 如5.1.1.1定义。
功率池应该在以下这个范围之内[40; -23] dB，单位步长dB，由物理层报给高层。
5.1.2 上行物理控制信道
5.1.2.1 UE行为
UE侧对发送功率定义如下：
[dBm]
其中
· ：UE最大发送功率，23dBm左右，见 [6]的6.2.2节。
· ：高层配置，每个一个配置的Each 值都是格式UCI1a的相对值，其中UCI1a不做调整，具体配置范围参见表5.4-1 [3]。
· ：PUCCH格式关系值，其中对应信道质量信息比特如5.2.3.3 [4]，HARQ比特数。
o 对于PUCCH格式1,1a and 1b：
o 对于PUCCH格式2, 2a, 2b 和正常CP情况下：
o 对于PUCCH格式2和扩展CP情况下：
· ：是高层配置，等于 + 。
· ：是UE专属修正参数，对应于TPC命令，包括在DCI1A/1B/1D/1/2A/2或者DCI 3/3A中，他们的CRC分别用C-RNTI或者TPC-PUCCH-RNTI。
o UE会在PDCCH中检测DCI 3/3A或者DCI1A/1B/1D/1/2A/2的TPC命令，除非在DRX状态。
o 如果UE检测PDCCH中DCI 1A/1B/1D/1/2A/2的TPC成功，UE使用调整发送功率值
否则
§ 如果UE检测DCI 3/3A成功，UE利用TPC的调整，否则 = 0 dB.
o ，其中是当前帧PUCCH的发送功率的调整值大小，
§ 在FDD情况下, and .
§ 在TDD情况下，和值由表10.1-1给出。
§ dB值由信令PDCCH的DCI1A/1B/1D/1/2A/2中TPC对应给出，参见表5.1.2.1-1。
§ dB值由信令PDCCH的DCI3/3A中TPC对应给出，参见表5.1.2.1-1或者5.1.2.1-2。高层半静态配置。
§ 初始值由以下定义：
· 如果高层配置，
o
· 否则
o
§ 其中 是随机接入响应专有的TPC命令，参见6.2节。
§ 来自高层，对应总功率放大范围，从第一个preamble到最后一个preamble结束。
§ 如果UE已经达到最大发送功率值，正的TPC不再有效。
§ 如果UE已经达到最小发送功率值，负的TPC不再有效。
§ UE应该在以下情况下复位初始累加值
· 小区更改
· 正在进入或退出RRC激活状态
· 收到
· UE收到随机接入响应消息
§ TDD制式下，非上行发送子帧时，
Table 5.1.2.1-1: Mapping of TPC Command Field in DCI format 1A/1B/1D/1/2A/2/3 to values.
TPC Command Field in
DCI format 1A/1B/1D/1/2A/2/3
[dB]
0
-1
1
0
2
1
3
3
Table 5.1.2.1-2: Mapping of TPC Command Field in DCI format 3A to values.
TPC Command Field in
DCI format 3A
[dB]
0
-1
1
1
5.1.3 侦听参考符号
5.1.3.1 UE行为
UE发送侦听参考信号功率定义如下：
[dBm]
其中
· ：UE最大发送功率，23dBm左右，见 [6]的6.2.2节。
· 当时, 是一个4比特用户级的半静态配置参数， 由高层配置，步长 1dB，范围 [-3, 12] dB.
· 当时,是一个4比特用户级的半静态配置参数，高层配置，步长1.5dB，范围[-10.5,12] dB。
· ：是在子帧i上SRS的传输带
展开阅读全文
浙ICP备2021020529号-1 | 浙B2-20240490
