美国电缆标准(ANSI cable standards)

编号
中文名称
英文名称
ANSI E1.16-2002
娱乐技术.金属卤素灯镇流器动力电缆的结构标准
Entertainment Technology - Configuration Standard for Metal-Halide Ballast Power Cables
ANSI E1.27-1-2006
娱乐业技术.用于ANSI E1.11 (DMX512-A)和USITT DMX512/1990产品的便携式控制电缆的标准
Entertainment Technology - Standard for Portable Control Cables for use with ANSI E1.11 (DMX512-A) and USITT DMX512/1990 Products
ANSI J-STD-042-2002
电缆的应急警报信息
Emergency Alert Message for Cable
ANSI T1.307-2003
电信.防火标准.设备组件的可燃性要求以及电线和电缆的火焰传播要求
Telecommunications - Fire Resistance Criteria - Ignitability Requirements for Equipment Assemblies and Fire Spread Requirements for Wire and Cable
ANSI/AAMI EC53-1995
ECG电缆和导线
ECG Cables and Wires
ANSI/AAMI EC53A-1998
ECGA电缆和导线
ECG Cables and Wires
ANSI/API SPEC17E-2003
水下临时管道及电缆规范
Specification for Subsea Umbilicals
ANSI/ASTM A523-1996
高压管型电缆线路用平端无缝与电阻焊钢管规范
Specification for Plain End Seamless and Electric-Resistance-Welded Steel Pipe for High-Pressure Pipe-Type Cable Circuits
ANSI/ASTM D1047-1995
电线及电缆用聚氯乙烯套管规范(10.01)
Specification for Poly(Vinyl Cholride) Jacket for Wire and Cable (10.01)
ANSI/ASTM D1351-2002
电线和电缆用热塑性聚乙烯绝缘规范
Specification for Thermoplastic Polyethylene Insulation for Electrical Wire and Cable
ANSI/ASTM D1523-2000
工作温度90℃的电线和电缆用合成橡胶绝缘规范(10.01)
Specification for Synthetic Rubber Insulation for Wire and Cable, 90°C Operations (10.01)
ANSI/ASTM D2219-2002
工作温度为60℃的聚氯乙烯电线和电缆绝缘规范(10.01)
Poly(Vinyl Chloride) Insulation for Wire and Cable, 60°C Operation, Specification for (10.01)
ANSI/ASTM D2220-2002
工作温度为75℃的聚氯乙烯电线和电缆绝缘规范(10.01)
Poly(Vinyl Chloride) Insulation for Wire and Cable, 75°C Operation, Specification for (10.01)
ANSI/ASTM D2308-2002
电线和电缆用热塑聚乙烯包装物规范
Specification for Thermoplastic Polyethylene Jacket for Electrical Wire and Cable
ANSI/ASTM D2633-2002
电线和电缆用热塑性绝缘体和护套测试方法
Methods of Testing Thermoplastic Insulations and Jackets for Wire and Cable
ANSI/ASTM D2655-2000
额定电压达到2000伏的电线和电缆交联聚乙烯绝缘材料规范(10.02)
Specification for Crosslinked Polyethylene Insulation for Wire and Cable Rated 0 to 2000 V
ANSI/ASTM D2656-2000
额定电压2001V到35V的电线和电缆交联聚乙烯绝缘材料规范(10.02)
Specification for Crosslinked Polyethylene Insulation for Wire and Cable Rated 2001 to 35V (10.02)
ANSI/ASTM D2768-1995
导线和电缆通用乙烯和丙烯橡胶套管规范(10.02)
Specification for General-Purpose Ethylene-Propylene Rubber Jacket for Wire and Cable (10.02)
ANSI/ASTM D2770-2001
电线及电缆用耐臭氧乙丙橡胶整体绝缘材料及套管规范
Specification for Ozone-Resisting Ethylene-Propylene Rubber Integral Insulation and Jacket for Wire and Cable
ANSI/ASTM D2802-2003
电线和电缆用耐臭氧乙丙橡胶绝缘材料规范
Specification for Ozone-Resistant Ethylene-Propylene Rubber Insulation for Wire and Cable
ANSI/ASTM D3485-2002
预装配导线和电缆用可盘绕光滑壁聚乙烯导管规范
Specification for Smooth-Wall Coilable Polyethylene (PE) Conduit (Duct) for Preassembled Wire and Cable
ANSI/ASTM D3554-2001
电线和电缆用耐划痕热塑性高密度聚乙烯绝缘子规范
Specification for Track-Resistant Black Thermoplastic High-Density Polyethylene Insulation for Wire and Cable
ANSI/ASTM D3555-2001
电线和电缆用耐划痕交叉连接热塑性高密度聚乙烯绝缘子规范
Specification for Track-Resistant Black Crosslinked Thermosetting Polyethylene Insulation for Wire and Cable
ANSI/ASTM D4244-1995
重负载和超重负载丙烯腈丁二烯聚氯乙烯(NBR PVC)电线和电缆护套通用规范
Specification for General-Purpose, Heavy-Duty and Extra-Heavy Duty Acrylonitrile-Butadiene Polyvinyl Chloride (NBR PVC) Jackets for Wire and Cable (10.02)
ANSI/ASTM D4245-2002
工作温度为90℃干/75℃湿的电线和电缆的耐臭氧热塑性合成橡胶绝缘规范
Specification for Ozone-Resistant Thermoplastic Elastomer Insulation for Wire and Cable 90oC Dry/75oC Wet Operation
ANSI/ASTM D4246-2002
工作温度为90℃的电线和电缆的耐臭氧热塑性合成橡胶绝缘规范
Specification for Ozone-Resistant Thermoplastic Elastomer Insulation for Wire and Cable, 90oC Operation
ANSI/ASTM D4313-2003
电线及电缆用普通、重型及超重型交联氯化聚乙烯套管规范
Specification for General Purpose, Heavy-Duty, and Extra-Heavy-Duty Crosslinked Chlorinated Polyethylene Jackets for Wire and Cable
ANSI/ASTM D4314-1999
普通重负载和超重负载交叉链环的氯磺化聚乙烯电线和电缆护套规范(10.02)
Specification for General Purpose Heavy-Duty and Extra-Heavy-Duty Crosslinked Chlorosulfonated Polyethylene Jackets for Wire and Cable (10.02)
ANSI/ASTM D4363-1998
电线和电缆的热塑氯化聚乙烯套管规范
Specification for Thermoplastic Chlorinated Polyethylene Jacket for Wire and Cable
ANSI/ASTM D4565-1999
远程通信电线和电缆用绝缘体和套管物理和环境性能特性的试验方法(10.02)
Test Methods for Physical and Environmental Performance Properties of Insulations and Jackets for Telecommunications Wire and Cable (10.02)
ANSI/ASTM D4566-1998
远程通信电线和电缆用绝缘体和套管电气性能特性试验方法(10.02)
Test Methods for Electrical Performance Properties of Insulations and Jackets for Telecommunications Wire and Cable (10.02)
ANSI/ASTM D4568-1999
评价电缆填充物、溢流元件、聚烯烃线和电缆材料相容性的试验方法(10.02)
Test Methods for Evaluating Compatibility Between Cable Filling and Flooding Compounds and Polyolefin Cable Materials (10.02)
ANSI/ASTM D470-2005
电线和电缆用交联绝缘材料和护套的试验方法(10.01)
Methods of Testing Crosslinked Insulations and Jackets for Wire and Cable (10.01)
ANSI/ASTM D4730-2002
电信电线和电缆浸渍化合物规范
Specification for Flooding Compounds for Telecommunications Wire and Cable
ANSI/ASTM D4731-2002
电信电线和电缆用热充填化合物规范
Specification for Hot-Application Filling Compounds for Telecommunications Wire and Cable
ANSI/ASTM D4732-2002
电信电线和电缆用冷充填化合物规范
Specification for Cool-Application Filling Compounds for Telecommunications Wire and Cable
ANSI/ASTM D4872-1999
电线和电缆填充化合物介电试验的试验方法
Test Method for Dielectric Testing of Wire and Cable Filling Compounds
ANSI/ASTM D5424-2005
在立式电缆槽中燃烧电缆引起的烟雾遮避性的试验方法(10.02)
Test Method for Smoke Obscuration Caused by Burning Cables in a Vertical Configuration (10.02)
ANSI/ASTM D5537-2003
电缆或光缆绝缘材料在立式电缆槽装置中燃烧时热发散、火焰传播和质量损失测试的试验方法
Test Method for Heat Release, Flame Spread and Mass Loss Testing of Insulating Materials Contained in Electrical or Optical Fiber Cables When Burning in a Vertical Cable Tray Configuration
ANSI/ASTM D6070-2002
预组装电线和电缆用光壁可盘绕聚乙烯(PE)管道物理特性试验方法
Test Methods for Physical Properties of Smooth-Wall, Coilable Polyethylene (PE) Conduit (Duct) for Preassembled Wire and Cable
ANSI/ASTM D6096-2002
工作温度为90℃的电线和电缆聚氯乙烯绝缘体规范
Specification for Poly(vinyl Chloride) Insulation for Wire and Cable, 90 C Operation
ANSI/ASTM D6113-2003
使用锥形量热计对电气或光纤电缆含的绝缘材料的着火试验反应特性进行测定的标准试验方法
Test Method for Using a Cone Calorimeter to Determine Fire-Test-Response Characteristics of Insulating Materials Contained in Electrical or Optical Fiber Cables
ANSI/ASTM D866-1999
电线及电缆用丁苯合成橡胶套规范
Specification for Styrene-Butadiene (SBR) Synthetic Rubber Jacket for Wire and Cable (10.01)
ANSI/ASTM F1835-1997
电缆连接设备导则
Guide for Cable Splicing Installations
ANSI/ASTM F1837M-1997
热缩电缆端口密封规范(米制)
Specification for Heat-Shrink Cable Entry Seals (Metric)
ANSI/ASTM F1883-2003
用美国线规(AWG)或米制单位选择电线和电缆规格的实施规程
Practice for Selection of Wire and Cable Size, in AWG or Metric Units
ANSI/CEA 2030-2005
多用室内音频电缆标准
Multi Room Audio Cabling Standard
ANSI/CEA 600.33-1997
同轴电缆物理层和介质规范
Coax Cable Physical Layer and Medium Specification
ANSI/EIA 364-101-2000
电连接器、插孔和电缆组件或内连接系统的衰减试验程序
Attenuation Test Procedure for Electrical Connectors, Sockets and Cable Assemblies or Interconnection Systems
ANSI/EIA 364-102-1998
电连接器、插孔、电缆组件或互连装置的上升时间衰减试验程序
Rise Time Degradation Test Procedure for Electrical Connectors, Sockets, Cable Assemblies or Interconnection Systems
ANSI/EIA 364-107-2000
电连接器，插孔，电缆组件或互连装置的目测图和跳动试验程序
Eye Pattern and Jitter Test Procedure for Electrical Connectors, Sockets, Cable Assemblies or Interconnection Systems
ANSI/EIA 364-108-2000
电连接器、电缆组件或内连系统在适当的时候和Frequency Domain 测量的阻抗、反射系数、回波损失和电压柱波
Impedance, Reflection Coefficient, Return Loss, and VSWR Test Procedure Measured in the Time and Frequency Domain for Electrical Connectors, Cable Assemblies or Interconnection Systems
ANSI/EIA 364-38B-1999
电连接器.电缆拔出试验
Electric Connectors - Cable Pull-Out Test
ANSI/EIA 364-41A-1984
电连接器.圆形护套电缆弯曲试验程序
Electric Connectors - Circular Jacket Cable Flexing Test Procedure
ANSI/EIA 364-41C-1999
电连接器的TP-41型电缆挠曲试验程序
TP-41 Cable Flexing Test Procedure for Electrical Connectors
ANSI/EIA 364-43B-2000
电连接器的电缆夹紧(弯矩)试验程序
Cable Clamping (Bending Moment) Test Procedure for Electrical Connectors
ANSI/EIA 403-A-1990
公共天线电视设备用75欧姆精密同轴电缆连接器
Precision Coaxial Connectors for CATV Application (75 Ohms)
ANSI/EIA 429-1976
扁平电缆连接器的一般标准
Connectors, Electrical Flat Cable Type, General Specification for
ANSI/EIA 600.33-1997
共轴电缆物理层和介质规范
Coax Cable Physical Layer and Medium Specification
ANSI/EIA 700AOAE-2000
使用单连接器固定的1.27mm间距双排的具有不可移动的带式电缆接触的锥形连接件的详细规范
Detail Specification for Trapezoidal Connectors with Non-Removable Ribbon Cable Contacts on 1.27 mm Pitch Double Row Used with Single Connector Attachments (SCA2)
ANSI/EIA 700AOAF-2000
用于非常高密度电缆连接的0.8mm间距的锥形屏蔽连接器的详细规范
Detail Specification for Trapezoidal Shielded Connector 0.8 mm Pitch Used with Very High Density Cable Interconnect (VHDCI)
ANSI/EIA-364-101-2000
电连接器、插座、电缆附件或互连系统衰减试验程序
Attenuation Test Procedure for Electrical Connectors, Sockets and Cable Assemblies or Interconnection Systems
ANSI/EIA-364-102-1998
电连接器、插座、电缆附件或互连系统上升时间降低试验程序
Rise Time Degradation Test Procedure for Electrical Connectors, Sockets, Cable Assemblies or Interconnection Systems
ANSI/EIA-364-103-1998
电连接器、插座、电缆附件或互连系统传播延迟试验程序
Propogation Delay Test Procedure for Electrical Connectors, Sockets, Cable Assemblies or Interconnection Systems
ANSI/EIA-364-107-2000
电连接器、插座、电缆组件或互连系统的眼孔图样和不稳定性试验程序
Eye Pattern and Jitter Test Procedure for Electrical Connectors, Sockets, Cable Assemblies or Interconnection Systems
ANSI/EIA-364-108-2000
电连接器、电缆附件或互连系统在时间和频率域中测量的阻抗、反射系数、回程损耗和VSWR试验程序
Impedance, Reflection Coefficient, Return Loss, and VSWR Test Procedure Measured in the Time and Frequency Domain for Electrical Connectors, Cable Assemblies or Interconnection Systems
ANSI/EIA-364-38B-1999
电连接器.电缆拔出试验
Cable Pull-Out Test Procedure for Electrical Connectors
ANSI/EIA-364-41C-1999
电连接器TP-41电缆挠曲试验程序
TP-41 Cable Flexing Test Procedure for Electrical Connectors
ANSI/EIA-364-43B-2000
电连接器.电缆夹紧(弯曲瞬间)试验程序
Cable Clamping (Bending Moment) Test Procedure for Electrical Connectors
ANSI/EIA-700AOAE-2000
单个连接器连接用、间距为1.27mm、带状电缆、双排不可拆卸触点的梯形连接器的详细规范(SCA2)
Detail Specification for Trapezoidal Connectors with Non-Removable Ribbon Cable Contacts on 1.27 mm Pitch Double Row Used with Single Connector Attachments (SCA2)
ANSI/EIA-700AOAF-2000
极高密度电缆互连用间距0.8mm梯形屏蔽连接器的详细规范
Detail Specification for Trapezoidal Shielded Connector 0.8 mm Pitch Used with Very High Density Cable Interconnect (VHDCI)
ANSI/EIA/TIA -455-104A-1993
纤维光学电缆的循环弯曲试验
Fiber Optic Cable Cyclic Flexing Test
ANSI/EIA/TIA 455-6B-1992
光缆互连装置的电缆固着力的测试规程
Cable Retention Test Procedure for Fiber Optic Cable Interconnecting Devices
ANSI/EIA/TIA-455-37-1993
纤维光学电缆高低温的弯曲试验
Fiber Optic Cable Bend Test, Low and High Temperature
ANSI/ICEA P-54-440-2002
安装在电缆管道中的电缆的载流量
Ampacities of Cables Installed in Cable Trays
ANSI/ICEA S-101-699-2001
一般用途非局域网电信布线系统用3类非屏蔽双绞线室内电缆的技术要求
Category 3 Individually Unshielded Twisted Pair Indoor Cable For Use In General Purpose Non-LAN Telecommunications Wiring Systems Technical Requirements
ANSI/ICEA S-103-701-2004
上升电缆
Riser Cable
ANSI/ICEA S-105-692-2004
600伏特单层热固性绝缘公用地下配电电缆
600 Volt Single Layer Thermoset Insulated Utility Underground Distribution Cables
ANSI/ICEA S-108-720-2004
额定电压46至345KV的挤压绝缘电力电缆的标准
Standard for Extruded Insulation Power Cables Rated Above 46 through 345 KV
ANSI/ICEA S-532-1973
控制电缆、热电偶软线和仪器仪表用电缆
Control, Thermocouple Extension and Instrumentation Cables
ANSI/ICEA S-70-547-2000
抗风化聚烯烃包覆电线和电缆
Weather-Resistant Polyolefin-Covered Wire and Cable
ANSI/ICEA S-76-474-2005
中性线支撑的额定值600伏特的抗风化挤制绝缘电力电缆组件
Neutral-Supported Power Cable Assemblies with Weather-Resistant Extruded Insulation Rated 600 Volts
ANSI/ICEA S-80-576-2002
在远程通信布线系统技术要求中使用的1 & 2 类分别无屏蔽双绞室内电缆(有或无全屏蔽)
Category 1 & 2 Individually Unshielded Twisted Pair Indoor Cables (With or Without an Overall Shield) for Use in Communications Wiring Systems Technical Requirements
ANSI/ICEA S-81-570-2005
加固设计的600伏特电缆标准
Standard for 600 Volt Cables of Ruggedized Design
ANSI/ICEA S-84-608-2002
聚烯烃绝缘填充铜导线通信电缆的技术要求
Telecommunications Cable Filled, Polyolefin Insulated, Copper Conductor - Technical Requirements
ANSI/ICEA S-85-625-2002
空芯聚烯烃绝缘铜导体通信电缆的技术要求
Aircore, Polyolefin Insulated, Copper Conductor Telecommunications Cable - Technical Requirements
ANSI/ICEA S-86-634-2004
通信电缆直埋配电和服务线.技术要求
Telecommunications Cable Buried Distribution and Service Wire - Technical Requirements
ANSI/ICEA S-87-640-1999
室外光纤通信电缆
Optical Fiber Outside Plant Communications Cable
ANSI/ICEA S-90-661-2002
通信配线系统中使用的独立无屏蔽室内绞线对电缆.技术要求
Individually Unshielded Twisted Pair Indoor Cables for Use In Communication Wiring Systems - Technical Requirements
ANSI/ICEA S-94-649-2005
额定值5000-46000伏特的同轴中性电缆
Concentric Neutral Cables Rated 5,000-46,000 Volts
ANSI/ICEA S-97-682-2000
额定电压5000-46,000伏有保护设施的电力电缆
Utility Shielded Power Cables Rated 5000 - 46,000 Volts
ANSI/ICEA S-98-688-1997
聚烯烃绝缘铜导线宽频双扭线电缆空心
Broadband Twisted Pair Cable Aircore, Polyolefin Insulated, Copper Conductor
ANSI/ICEA S-99-689-1997
聚烯烃绝缘填充铜导线宽频双扭线电缆
Broadband Twisted Pair Cable Filled, Polyolefin Insulated, Copper Conductor
ANSI/ICEA T-26-465-2000
试验用压模绝缘体电缆、控制电缆、测量仪器电缆和轻便电缆频繁取样的指南
Guide for Frequency of Sampling Extruded Dielectric Power, Control, Instrumentation, and Portable Cables for Test
ANSI/IEEE 1017-2004
潜水电泵电缆的现场试验推荐规范
Recommended Practice for Field Testing Electric Submersible Pump Cable
ANSI/IEEE 1018-2004
规定潜水电泵电缆用推荐规程.乙烯-丙烯橡胶绝缘
Recommended Practice for Specifying Electric Submersible Pump Cable - Ethylene-Propylene Rubber Insulation
ANSI/IEEE 1019-2004
规定潜水电泵电缆用推荐规程.聚丙烯绝缘
Recommended Practice for Specifying Electric Submersible Pump Cable - Polypropylene Insulation
ANSI/IEEE 1073.3.2-2000
医疗装置通信.传输轮廓.以IrDA为基的连接电缆
Medical Device Communications - Transport Profile - IrDA Based - Cable Connected
ANSI/IEEE 1120-2004
海底电力和通信电缆的规划、设计和安装中所考虑因素的指南
Guide to the Factors to Be Considered in Planning, Design, and Installation of Submarine Power and Communication Cable
ANSI/IEEE 1143-1994
低压电缆屏蔽实施指南
Guide on Shielding Practice for Low Voltage Cables
ANSI/IEEE 1185-1994
发电站电缆的安装方法指南
Guide for Installation Methods for Generating Station Cables
ANSI/IEEE 1202-1991
工业和商业中走线架内用电缆的燃烧试验
Flame Testing of Cables for Use in Cable Tray in Industrial and Commercial Occupancies
ANSI/IEEE 1210-2004
使用电线和电缆测定电缆润滑剂可混用性的标准试验
Standard Tests for Determining Compatibility of Cable Lubricants with Wire and Cable
ANSI/IEEE 1235-2000
地下电力电缆和管道用可识别护套的特性指南
Guide for the Properties of Identifiable Jackets for Underground Power Cables and Ducts
ANSI/IEEE 1242-19
