微混合器研究进展.ppt

单击此处编辑母版标题样式,.,*,单击此处编辑母版文本样式,第二级,第三级,第四级,第五级,微混合器研究进展,Seminar ,学生：赵玉潮,导师：袁 权 院 士,陈光文 研究员,微化工技术组,2006/5,.,主要内容,材质与加工方法,流动特性分析,微混合器分类,混合效果评价方法,.,（一）材质与加,工方法,不锈钢,铝片,硅,石英和玻璃,硬质高分子聚合物,弹性聚合物,光敏聚合物,机械微加工,湿法刻蚀,干法刻蚀,高分辨刻蚀,(LIGA),注塑,原位聚合,热压,气相沉积,软刻蚀,.,（二）微混合器内流体流动特点,尺度小,（,0.01mm10mm,）,Re2000,层流,扩散！,Einstein,理论：,水分子扩散,10m,约需,1s,扩散,1mm,约需,1000s,布朗运动的扩散系数：,流体性质本身、温度和一些常数有关,强化混合过程,L,操作和加工难度,两流体间接触面积，二次流（横向速度），,外加能量，微通道结构和壁面,注意：,.,微尺度下混合原则,Injection of substream,Periodic injection,Splitting and recombination,Injection into a main stream,Forced mass transport,contacting,Decrease of diffusion path,High energy collision,.,（三）微混合器分类,主动式,从动式,微混合器,有无动力源,并行迭片,串联迭片,注射,/,喷射,混沌对流,作用原理,脉冲扰动,电场扰动,磁动力,超声波,电动力,热扰动,能量种类,.,从动式微混合器的特点,优点,结构简单,操作稳定,容易集成,成本较低,易自动化,缺点,混合时间长,混合效果差,浓度脉动谱,惯性对流子域,粘性对流子域,粘性扩散子域,宏观湍流分散,介观粘性变形,微观分子扩散,流体间的剪切 和小尺度拉伸、折叠,接触面积 扩散路径,.,平行迭片,从动式,两股流体通过两个入口同时进入一个长的混合微通道，接触后相互扩散而进行混合,设计理念：,研究最多、最简单、最重要的微混合器：,“,T”,型微混合器,“,Y”,型微混合器,研究微尺度下传递现象的理想设备，如放大（缩小）法则、蝴蝶效应、以及其它非线性现象,Kockmann,把微通道内层流区域流型分为三种情况：即严格层流、涡流、席卷流；,Wong,等发现,Re,数在,400,500,，流速达,7.6m/s,，流体能够较好混合，压力高达,700kPa,，给微反应系统的封装和连接带来了挑战！,.,平行迭片,从动式,二次流现象：,与流体主流方向垂直，强化混合过程,边界层分离：,这种分离能够形成漩涡，使流体层破裂形成转动方向不同的小漩涡，减少扩散距离，强化混合过程,微尺度下通道内存在弯曲点、不规则突起或节点时，使二次流和边界层分离容易发生,“,Z”,字型微混合器,.,平行迭片,从动式,“水力学聚焦”原理微混合器，减小横向扩散路径,时间交叉分段与“水力学聚焦”组合式微混合器,.,平行迭片,IMM,公司的,Ehrfeld,小组设计了一种交趾式微混和器,从动式,.,串联迭片,从动式,入口两流体首先水平呈一股流体流动，然后被垂直分割，再水平汇合，重复此过程，经过,m,次汇合和分割后，则会出现,2,m,层薄层流体，能够使混合时间减小,4,m-1,倍,定义：,串联迭片,分割汇合,分割分割汇合,.,串联迭片,从动式,通过优化微通道结构，使流体层层叠加，,He,等设计了一种小体积、小流速的微混合器,.,注射式微混合器,从动式,一相主体流顶部或底部存在一系列喷嘴，而另一种流体通过这些喷嘴喷射入主体流中形成羽状流，这种羽状流能够增加两相接触面积和减小混合路径，强化混合过程,定义：,注射式微混合器二维模型,式中，,K,0,，,K,1,分别为第二类变形贝塞耳函数；,Pe,数和无量纲浓度,c,*,分别为：,Miyake,等采用,DRIE,方法在硅片方形混合室内加工了,400,个喷嘴；,Larsen,等利用,CFD,模拟方法研究了喷嘴形状对混合的影响；,.,混沌对流,从动式,中等雷诺数区域（,10Re5,时混合效果就能达到理想效果,.,混沌对流,从动式,中等雷诺数区域（,10Re100,）：,Liu,等报导了一种由“,C”,型微混合单元串联并垂直排列而成的三维蛇形微混合器,“,T”,型入口方式，六个微混合单元，微通道总长度为,20mm,。仅在相对高的雷诺数下（,Re=2570,），混沌对流才能够发生,.,混沌对流,从动式,中等雷诺数区域（,10Re100,）：,“,L”,型,改进“,L”,型,流动折叠拓扑结构,旋转型,其它类型微混合器,.,混沌对流,从动式,低雷诺数区域（,Re10,）：,Johnson,等首次发现微通道壁面上的凹槽能够产生混沌对流，以电力驱动流体流动，在低雷诺数下就能获得较好的混合效果：,Stroock,等研究了两种不同凹槽结构对混合的影响，如交错排列的箭尾形结构,.,主动式微混合器的特点,优点,混合时间短,混合距离短,可选择性大,适于极低,Re,数,缺点,不易集成,成本较高,制作困难,材质要求高,.,脉冲扰动,主动式,压力扰动,速度脉冲侧线进料,微搅拌（外加电磁场）,.,电场扰动,主动式,Moctar,等把电极置于微通道内，改变电极两端电压和频率，使两种不同性质的流体按不同轨迹运动，在微通道内产生混沌对流，结果发现在,Re=0.02,时就能达到较好混合效果,.,其它能量形式,磁动力：在外加磁场作用下，电极上产生直流电，使电解质溶液中带电粒子受到罗仑兹力，并带动流体翻转、折叠，增加接触面积；,超声波：用声波来搅拌微混合器内的流体；,电动力：通过外加电流，改变电渗流速度大小和方向，产生混沌对流，达到强化混合过程的目的,；,热扰动：改变扩散系数,D,，如利用热泡产生流体扰动，以强化混合过程,主动式,.,（四）混合效果评价,可视化方法,标记物技术,微粒成像技术,共聚焦检测技术,竞争反应法,平行竞争反应,连串竞争反应,浓度轮廓分布法,光学法,微传感器,红外光谱法,拉曼光谱法,评价方法,理论模拟,CFD,.,混合效果评价,可视化方法,标记物技术,共聚焦检测技术,微粒成像技术（实验）,微粒成像技术（模拟）,.,混合效果评价,竞争反应法,传统工程学派方法：,.,参考文献,1,微流控分析芯片的制作及应用，方肇伦主编，,2005,；,2 M.Kakuta,F.G.Bessoth and A.Manz,Microfabricated devices for fluid mixing and their application for chemical synthesis,Chem.Rec.1(2001),395-405.,3 J.M.Ottino,W.E.Ranz,C.W.Macosko,Chem.Eng.Sci.,1979,34:877-890.,4 A.E.Kamholz and P.Yager,Molecular diffusive scaling laws in pressure-driven microfluidic channels:deviation from one-dimensional Einstein approximations,Sensor Actuators B,82(2002),117121.,5 S.H.Wong,M.C.L.Ward,C.W.Wharton,Micro T-mixer as a rapid mixing micromixer,Sensors and Actuators B:Chemical,2004,100,365-385.,6 S.H.Wong,，,M.C.L.Ward,，,C.W.Wharton,，,Micro T-mixer as a rapid mixing micromixer,，,Sensors and Actuators B,2004,，,100,，,359379.,7 M.Koch,H.Witt,A.G.R.Evans and A.Brunnschweiler,Improved characterization technique for micromixer,J.Micromech.Microeng.9(1999),156-158.,8 J.B.Knight,A.Vishwanath,J.P.Brody and R.H.Austin,Hydrodynamic focusing on a silicon chip:mixing nanoliters in microseconds,Phys.Rev.Lett.80(1998),38633866.,9 N.T.Nguyen,X.Y.Huang,Mixing in microchannels based on hydrodynamic focusing and time-interleaved segmentation:modelling and experiment,Lab Chip,2005,5,13201326.,10 B.He,B.J.Burke,X.Zhang,R.Zhang,F.E.Regnier,A picoliter-volume mixer for microfluidic analytical systems,Anal.Chem.2001,73,19421947.,11 W.Ehrfeld,V.Hessel,S.Kiesewalter,H.Lwe,T.Richter,J.Schiewe,Microreaction Technology:Industrial Prospects;Springer:Berlin,2000;p14.,12 B.L.Gray et al,Novel interconnection technologies for integrated microfluidic systems,Sensors Actuators A,77(1999),5765.,13 M.S.Munson and P.Yager,Simple quantitative optical method for monitoring the extent of mixing applied to a novel microfluidic mixer,Anal.Chim.Acta,507(2004),6371.,.,14 V.Mengeaud,J.Josserand and H.H.Girault,Mixing processes in a zigzag microchannel:finite element simulation and optical study,Anal.Chem.74(2002),42794286.,15 N.T.Nguyen and Z.G.Wu,Micromixers-a review,J.Micromech.Microeng.15(2005),1-16.,16 C.C.Hong,J.W.Choi and C.H.Ahn,A novel in-plane microfluidic mixer with modified tesla structures,Lab on a Chip 4(2004),109113.,17 R.H.Liu et al,Passive mixing in a three-dimensional serpentine microchannel,J.Microelectromech.Syst.9(2000),190197.,18 R.A.Vijiayendran et al,Evaluation of a three-dimensional micromixer in a surface-based biosensor,Langmuir,19(2003),18241828.,19 H.Chen and J.C.Meiners,Topologic mixing on a microfluidic chip,Appl.Phys.Lett.84(2004),21932195.,20 S.J.Park et al,Rapid three-dimensional passive rotation micromixer using the breakup process J.Micromech.Microeng.14(2004),614.,21 C.P.Jen et al,Design and simulation of the micromixer with chaotic advection in twisted microchannels,Lab on a Chip,3(2003),7781.,22 T.J.Johnson,D.Ross and L.E.Locascio,Rapid microfluidic mixing,Anal.Chem.74(2002),4551.,23 A.D.Stroock,S.K.W.Dertinger,A.Ajdari,I.Mezic,H.A.Stone and G.M.Whitesides,Chaotic mixer for microchannels,Science,295(2002),647-651.,24 Fujii et al,A plug and play microfluidic device,Lab on a Chip,3(2003),193197.,25 I.Glasgow and N.Aubry,Enhancement of microfluidic mixing using time pulsing,Lab on a Chip,3(2003),114120.,26 L.H.Lu,K.S.Ryu and C.Liu,A magnetic microstirrer and array for microfluidic mixing,J.Microelectromech.Syst.11(2002),462469.,27 A.O.El Moctar,N.Aubry and J.Batton,Electrohydrodynamic micro-fluidic mixer,Lab on a Chip,3(2003),273280.,参考文献,(,续,),.,28 H.H.Bau,J.Zhong and M.Yi,A minute magneto hydro dynamic(MHD)mixer,Sensors Actuators B,79(2001),207215.,29 J.C.Rife et al,Miniature valveless ultrasonic pumps and mixers,Sensors Actuators A 86(2000),135140.,30 S.C.Jacobson,T.E.McKnight and J.M.Ramsey,Microfluidic devices for electrokinematically driven parallel and serial mixing,Anal.Chem.71(1999),44554459.,31 H.Mao,T.Yang and P.S.Cremer,A microfluidic device with a linear temperature gradient for parallel and combinatorial measurements,J.Am.Chem.Soc.124(2002),44324435.,32 J.H.Tsai and L.Lin,Active microfluidic mixer and gas bubble filter driven by thermal bubble pump,Sensors Actuators A,9798(2002),665671.,33 J.R.Bourne,F.Kozicki,P.Rys,Mixing and fast chemical reactiontest reactions to determine segregation,Chem.Eng.Sci.1981,36,1643.,34 A.Karoui,F.Hakenholz,N.Le Sauze,J.Costes,J.Bertrand,Determination of the mixing performance of Sulzer SMV static mixers by laser induced fluorescence,Can.J.Chem.Eng.1998,76,522.,35 A.D.Stroock and G.M.Whitesides,Controlling flows in microchannels with patterned surface charge and topography,Acc.Chem.Res.36(2003),597604.,36 R.F.Ismagilov et al,Experimental and theoretical scaling laws for transverse diffusive broadening in two-phase laminar flows in microchannels,Appl.Phys.Lett.76(2000),23762378.,37 W.Ehrfeld,K.Golbig,V.Hessel,H.Loewe,T.Richter,Characterization of mixing in micromixers by a test reaction:single mixing units and mixer arrays,Ind.Eng.Chem.Res.1999,383,1075.,38 M.C.Fournier,L.Falk,J.Villermaux,A new parallel competing reaction system for assessing micromixing efficiencyexperimental approach,Chem.Eng.Sci.1996,51,5053.,39 P.Guichardon,L.Falk,Characterization of micromixing efficiency by the iodideiodate reaction system.Part I.Experimental procedure,Chem.Eng.Sci.2000,55,4233.,40 Loebbecke,S.,et al.,2000.Applications of FTIR microscopy for process monitoring in silicon microreactors.In:VDE World Microtechnologies Congress,MICRO.tec 2000,EXPO Hannover.VDE Verlag,Berlin,pp.789791.,41 V.Hessel,et al.,2003.Laminar mixing in different interdigital micromixerspart I:experimental characterization.A.I.Ch.E.49(3),566577.,参考文献,(,续,),.,谢谢大家！,.,
