连云港VTS用户指南精品文档船舶报告SHIPS REPORT交通服务TRAFFIC SERVICE到港预报： 发给：连云港海事局 内容：IMO SRS 代码： A B G I O P Q T U 时限：按主管机关要求 通过：代理过门线报告： 时间：抵达VTS区域门线时 内容：船名、国籍、吃水及VTS中心需要的信息抛、起锚报告： 时间：抛锚完毕 内容：船名、抛锚时间及锚位 时间：起锚前30分钟 内容：船名、预计起锚时间及动态位置报告： 时间：进入航道、驶出航道、靠泊完毕、驶离泊位 内容：船名、位置及动向紧急情况报告： 时间：船舶发生或发现交通事故、污染事故等紧急情况时 内容：事故发生时间、地点、装载、损失情况、事故原因异常情况报告： 时间：船舶发现助航标志异常、有碍航行安全的障碍物、漂浮特及其它妨碍航行安全的异常情况时 内容：时间、位置及发现的异常情况ETA report: TO: Lianyungang Maritime Safety Administration Giving: IMO SRS Code: A, B, G, I, O, P, Q, T, U Time limit: As required by the competent authority Via: AgentPassing gate line report:Time: Arrived at the VTS Area gate lineGiving: vessels name, nationality, draft and other information required by VTS CenterAnchoring or heaving up anchor report:Time: Finishing dropping anchorGiving: Vessels name, time of dropping anchor and anchor positionTime: 30 minutes before heaving up anchorGiving: vessels name and expected time of heaving up anchor and intended movementTime: entering and leaving channels, berthing , leaving berthGiving: Vessels name, position and intended movementEmergency report:Time: Whenever a maritime accident or pollution accident occurs or is foundGiving: Time and position of the accident, loading, damages and causes of the accidentAbnormal reports:Time: Whenever the vessel finds abnormality of navigation aids, obstacles to impede the safety of navigation, floating objects and other abnormal circumstances to impede the safety of navigationGiving: Time and position and the abnormal circumstances foundVTS中心可以提供：航警服务：航行通（警）告信息，水文气象信息，船舶动态信息或其它重要安全信息。咨询信息服务：港口水域地理情况，水文气象信息、船舶动态信息、港口有关规章和其它有关信息。航行助航服务：船舶定位、测定船舶操纵行动效果、助航、航行建议、搜寻船舶等目标和其它有关安全航行等信息。交通组织服务：连云港航道使用实行审批制度，VTS中心可对船舶航行计划进行调整。支持联合行动：在搜寻救助等联合行动中，VTS中心可为船舶传递有关信息。其它交通服务。VTS Center may provide:Navigational warning services: important safety massages including navigational warnings, notices to mariner, hydraulic and weather forecast, vessels movements or others.Consultant services: Geographic information, hydraulic and weather forecast, vessels movements within the port waters, relevant port regulations and rules, and other relevant information.Navigational assistance services: Position fixing, measuring the effectiveness of ship handing action, navigational assistance, navigation advice, searching for vessels or other objects, and other massages related to navigation safety.Traffic organization services: Using Lianyungang Channels shall be approved. VTS Center may adjust the vessels sailing plans.Support of allied activities: VTS Center may distribute relevant massages to the participating vessels during the allied activities such as search and rescue.Other traffic services通信程序Communication Procedures禁止和许可Prohibitions & PermissionsVTS中心通信频道安全值守频道： 16业务通话频道： 66播发航警频道： 69Channels used by VTS Center:Safety watching channel: 16Communication channel 66Navigational Warning broadcasting channel: 69呼叫：连云港交管Calling: Linayungang VTS注意：在VTS区域所有船舶应在VHF CH.16上保持守听。Attention: All the vessels within the VTS Area shall keep watch on VHF channel 16 航行通（警）告播发时间为北京时间：1000时、1500时。 The times for broadcasting navigation warnings are 1000&1500 Beijing Time. 和外运代理、港务局调度、引航公司等港口单位联系可通过VHFCH16呼叫连云港海岸电台接转。 Vessels shall call Lianyungang Coast Radio station via VHF 16 to contact the harbor Services such as the Agency, Harbor Operation or Pilotage etc.禁止：（A） 船舶在航道、港池、掉头区及禁锚区锚泊；（B） 在航道、锚地、港池、掉头区及其附近水域内捕捞和养殖；（C） 抛弃任何废弃物；（D） 船舶在助航标志上系泊。Prohibitions:(A) No vessels shall anchor in the Channels, port basins , turning areas and prohibited anchorage;(B) No fishing or cultivation is allowed in the channels, anchorage, port basins, turning areas and their adjacent waters;(C) No wastes or garbage shall be dumped into this Port;(D) No vessels shall be moored to the navigation aids.船舶进行列活动，必须经VTS中心许可：（A） 外国籍船舶和300总吨及以上的中国籍船舶使用航道（需提前1小时申请）。（B） 在航道内吊拖、试航、测速。（C） 船舶在锚地以外的通航水域锚泊。（D） 船舶在引航检疫锚地进行过驳作业。（E） 船舶在内港一号锚地锚泊。（F） 锚泊时进行下列事项：1、 拆修主机、锅炉、锚机、舵机；2、 试车、试航、试笛、试放火箭信号、校对罗经；3、 放艇（筏）进行救生演习。（G） 船舶在锚地并靠。Vessels to carry out the following operations shall get permissions from the VTS Center:(A) Any vessel of foreign nationalities and any Chinese vessels of 300 gross tonnage or above using the channels (They shall make an application 1 hour in advance).(B) Towing, making a navigation trial or speed testing in the Channels.(C) Anchoring outside the anchorage in the navigable waters.(D) Carrying out cargo transffering operations at the Pilot & Quarantine Anchorage.(E)Anchoring at the Anchorage NO.1 in Inner Port Area.(F)While anchoring:1. Overhauling main engine, boiler, windlass or steering gear;2. Testing main engine, navigation trial, testing siren, testing rockets or flare signals and calibrating magnetic compass;3. Launching life craft for drill. (G) Getting alongside another vessel at anchorage.区 域 名 称Area Names区 域 界 定Area Boundaries说 明Descriptions主航道Main Channel从号灯浮标到22号灯浮标。其中：主航道甲段从1号灯浮标到9号灯浮标；主航道弯段从9号灯浮标到11号灯浮标；主航道乙段从11号灯浮标到22号灯浮标。From light buoy NO.1 to NO.22. Main Channel Part A is from light buoy NO.1 to NO.9; Main Channel Bend is from light buoy NO.9 to NO.11; Main Channel Part B is from light buoy NO.11 to NO.22.全长12.5海里，通航水深-11.0米；主航道甲段10.5海里，轴向243063，底宽170米，设标宽度280米；主航道弯段长约0.5海里，轴向267.5087.5，底宽370米，设标宽度490米；主航道乙段长约1.5海里，轴向292112，底宽170米，设标宽度280米。Total length 12.5 nautical miles, navigable depth 11.0m; Main Channel Part A: length 10.5 miles, bearing 243-063, bottom breadth 170m, breadth between buoys 280m; Main Channel Bend: length about 0.5 miles, bearing 267.5-087.5, bottom breadth 370m, breadth between buoys 490m; Main Channel Part B: length about 1.5 miles, bearing 292-112, bottom breadth 170m, breadth between buoys 280m.庙岭航道Miaoling Channel从22号灯浮标到51号灯浮标。其中：庙岭航道甲段从22灯浮标到33号灯浮标；庙岭航道乙段从33号灯浮标到51号灯浮标。From light buoy NO.22 to NO.51, In this channel, Part A is from light buoy NO.22 to NO.33; Part B from light buoy NO.33 to NO.51.全长2.7海里，通航水深-11.0米，底宽140米，设标宽度230米。其中：庙岭航道甲段长约0.9海里，轴向292112；庙岭航道乙段长约1.8海里，轴向270090。Total length 2.7 miles, navigable depth 11.0m, bottom depth 140m, breadth between buoys 230m. In this channel, Miaoling Channel Part A is length 0.9 miles, bearing 292-112; Miaoling Channel Part B is length about 1.8 miles, bearing 270-090.墟沟航道Xugou Channel从51号灯浮标到54号灯浮标。From light buoy NO.51 to NO.54.全长约0.9海里，底宽约100米，通航水深-7.0米，轴向270-090，设标宽度150米。Total length about 0.9 miles, bottom breadth about 100m, navigable depth 7.0m, bearing 270-090, breadth between buoys 150m.老港区航道Old Port Channel从22号灯浮标到23号灯浮标。From light buoy NO.22 to NO.23.全长约0.5海里，底宽120米，通航水深-8.6米，轴向270-090，设标宽度170米；Total length about 0.5 miles, bottom breadth 120m, navigable depth 8.6m, bearing 270-090, breadth between buoys 170m.大型船舶锚地Large Vessles Anchorage 以连云港羊窝头灯塔真方位239，距离16海里处为中心，1.5海里为半径的圆形水域 。A circular area with 1.5 miles of radius, centered at 16 miles 239 true from Yangwotou light house.水深1619米。The depth is 16m19m.一号引航检疫锚地Pilot & Quarantine Anchorage NO.1以连云港羊窝头灯塔真方位258 ，距离15海里处为中心，1.5海里为半径的圆形水域。A circular area with 1.5 miles of radius, centered at 15 miles 258 true from Yangwotou light house.水深1517米。The depth is 15m17m.区域名称（续上表）Area Names（Continued）区 域 界 定（续上表）Area Boundaries（Continued）说 明(续上表)Descriptions（Continued）危险品船舶锚地Dangerous Goods Anchorage以连云港羊窝头灯塔真方位263，距离10海里处为中心，1.0海里为半径的圆形水域。A circular area with 1.0 miles of radius, centered at 10 miles 263true from Yangwotou light house.水深1113米。The depth is 11m13m.二号引航检疫锚地Pilot & Quarantine Anchorage NO.2以连云港羊窝头灯塔真方位240，距离海里处为中心，1.0海里为半径的圆形水域 。 A circular area with 1.0 miles of radius, centered at 4 miles 240 true from Yangwotou light house.水深79米。The depth is 7m9m.三号引航检疫锚地Pilot & Quarantine Anchorage NO.3以连云港羊窝头灯塔真方位271，距离1.6海里处为中心，0.5海里为半径的圆形水域 。A circular area with 0.5 miles of radius, centered at 1.6 miles 271 true from Yangwotou light house.水深56米。其中344455N，1193115E与344518N，1193210E两点连线以南部分停止使用。The depth is 5m6m, but the use of the south of a line joining 344455N，1193115E and 344518N，1193210E ceased.老港区掉头区Old Port Turning Area以北纬344434.2，东经1192658.1处为中心，200米为半径的圆形水域。The circular area with 200 m of radius, centered at 344434.2N, 1192658.1E.通航水深-8.6米。Navigable depth 8.6m.庙一掉头区Miaoling NO.1 Turning Area以北纬344503.066，东经1192507.352处为圆心，260米为半径的圆形水域。The circular area with 260m of radius, centered at 344503.066N, 1192507.352E.通航水深-12.0米。 Navigable depth 12.0m.庙二掉头区Miaoling NO.2 Turning Area以北纬344458.7，东经1192525.9处为中心，225米为半径的圆形水域。The circular area with 225 m of radius, centered at 344458.7N, 1192525.9E.通航水深-8.7米。Navigable depth 8.7m.墟沟掉头区Xugou Turning Area以北纬344501，东经1192329.5处为中心，160米为半径的圆形水域。The circular area with 160 m of radius, centered at 344501N, 1192329.5E.通航水深-7.0米。Navigable depth 7.0.注：连云港避风锚地位于内港水域内。Note: Shelter Anchorage in Lianyungang Port is within the Inner Port Waters.收集于网络，如有侵权请联系管理员删除
