iwatt3614变压器设计参数.pptx

27 Jan.20111MATERIALS:1.Core:RM-8(Ferrite Material TDK PC40 or equivalent)2.Bobbin:RM-83.Magnet Wires(Pri):Type 2-UEW 4.Magnet Wire(Sec):Triple Insulated Wires 5.Layer Insulation Tape:3M1298 or equivalent.SCHEMATIC 40V 0.42mA ELECTRICAL SPECIFICATIONS:1.Primary Inductance(Lp)=0.4610%mH 10KHz2.Primary Leakage Inductance(Lk)70uH10KHzFINISHED:1.Cut remained of Pin1,3,12,4,6,after wires termination2.Varnish the complete assembly3.Core is connected to primary pin611246Primary 2 19TBias 11T0.23mmx 11T Second clockwise Triple Insulation wire2UEW 0.21mmx2 19T Primary1BottomClockwise looking at pin 1-6 side PRISec12(S)0.23mmx 10T Second clockwise Triple Insulation wire2UEW 0.23mmx2 17T Primary2Secondary 21T6(F)1(F)3(F)3(S)3Primary 1 19T4(S)4(S)2UEW 0.17mmx2 11T Primary1(clockwise)2UEW 0.17mmx2 11T shield(clockwise)6(S)6(S)(F)飞线(S)Sec7Sec161227 Jan.20112MATERIALS:1.Core:RM-8(Ferrite Material TDK PC40 or equivalent)2.Bobbin:RM-83.Magnet Wires(Pri):Type 2-UEW 4.Magnet Wire(Sec):Triple Insulated Wires 5.Layer Insulation Tape:3M1298 or equivalent.SCHEMATIC 40V 0.40mA ELECTRICAL SPECIFICATIONS:1.Primary Inductance(Lp)=0.4810%mH 10KHz2.Primary Leakage Inductance(Lk)70uH10KHzFINISHED:1.Cut remained of Pin1,3,12,4,5,after wires termination2.Varnish the complete assembly3.Core is connected to primary pin411245Primary 2 17TBias 11T0.23mmx11T Second clockwise Triple Insulation wire2UEW 0.21mmx2 19T Primary1BottomClockwise looking at pin 1-6 side PRISec12(S)0.23mmx 10T Second clockwise Triple Insulation wire2UEW 0.21mmx2 19T Primary2Secondary 21T5(F)1(F)3(F)3(S)3Primary 1 17T4(S)4(S)2UEW 0.17mmx2 11T Primary1(clockwise)2UEW 0.17mmx2 11T shield(clockwise)5(S)5(S)(F)飞线(S)Clockwise looking at pin 1-6 side PRISec7Sec161227 Jan.20113MATERIALS:1.Core:RM-8(Ferrite Material TDK PC40 or equivalent)2.Bobbin:RM-83.Magnet Wires(Pri):Type 2-UEW 4.Magnet Wire(Sec):Triple Insulated Wires 5.Layer Insulation Tape:3M1298 or equivalent.SCHEMATIC 40V 0.36mA ELECTRICAL SPECIFICATIONS:1.Primary Inductance(Lp)=0.5410%mH 10KHz2.Primary Leakage Inductance(Lk)70uH10KHzFINISHED:1.Cut remained of Pin1,3,12,4,6,after wires termination2.Varnish the complete assembly3.Core is connected to primary pin611246Primary 2 19TBias 11T0.23mmx11T Second clockwise Triple Insulation wire2UEW 0.21mmx2 19T Primary1BottomClockwise looking at pin 1-6 side PRISec12(S)0.23mmx 10T Second clockwise Triple Insulation wire2UEW 0.21mmx2 19T Primary2Secondary 21T6(F)1(F)3(F)3(S)3Primary 1 19T4(S)4(S)2UEW 0.17mmx2 11T Primary1(clockwise)2UEW 0.17mmx2 11T shield(clockwise)6(S)6(S)(F)飞线(S)7Sec1612
