45ºmitred joint 45º斜接缝
a complete 成套设备
a lamination stack 一叠铁心
A-A enlarged A-A放大
A-A section A-A剖面
abbreviation 缩写
abscissa X-axis 横坐标
absorbent 吸附剂
absorption ratio of insulation resistance 绝缘电阻吸收比
acceleration 加速度
acceptance inspection 验收检验
accessories 附件
accuracy 准确度
accuracy class 准确级次
accuracy limit factor 准确限值因数
acetic acid ethylic 醋酸
acetone 丙酮
acetone extraction of insulating material 绝缘材料丙酮抽出物
acetylene 乙炔
acid value 酸值
acryl 丙烯
active aluminium oxide (activated alumine) 活性氧化铝
active part assembly 器身装配
additional insulation of lead 引线附加绝缘
additional loss 附加损耗
admittance 导电率
air (water) cooler 风（水）冷却品
air core reactor 空心电抗器
air exhausting pipe 导气管
air gap 空气隙
alignment 对中心（不对中心）　
alkyd base lacquer 酚醛漆
aluminium-alloy conductor 铝合金导线
ambient temperature 环境温度
angle 角钢（槽钢）
angular contact ball bearing 向心止推滚珠轴承　
annealed conductor 退火导线
annex (appendix) to the contract　 合同附件
annular gear 内齿轮
anticoagulent 抗凝剂
anti-corna coating 防叠层　
anti-dust washer 防尘垫圈　
anti-magnetic steel (low-temperature steel) 抗磁钢（低温钢）
antioxidant 抗氧化剂
antirust primer 防锈底漆
apparent charge 视在电荷
approximate 近似于
arc-suppression reactor 消弧电抗器
argon protected welding 氩弧焊
ascending flanged base 升高座
assignment for technical design 技术任务书　
atmospheric over voltage 大气过电压
autographic recording instrument 自动记录仪表
automatic assembly scaffold 自动升降装配架
automatic lathe 自动车床
automatic submerged-arc wilding 埋弧自动焊
autotransformer 自耦变压器
autotransformer regulator 自耦调压器
auxiliary winding 辅助线圈
availability 可用性
axial (radial) leakage flux 轴向（径向）漏磁通
axial strip 轴向撑条
aximum (minimum) tapping　 最大最小分接m
backing off lathe 铲背车床
bakelite coated insulating paper 上胶绝缘纸
bakelized paper board(cpoxy resin glass-fibre) 胶纸板（环氧玻璃布板）　
balance reactor 平衡电抗器
ballast 镇流器
band saw 带锯床
band spring 板弹簧
banding wire (rope) 绑线（绳）
barrel (petroleum) 桶（石油）
base plate of rating plate 铭牌底板
basic parts 基础件
B-B tuned by B-B转
beaker　 烧杯
beaker flask 坩埚
beaker flask 锥形瓶
bearing 轴承
bell type tank 钟罩式油箱
bench drill 台钻
bending die for steel tube 钢管压弯模
bending press 折板机　
bending press (brake) 折板机（液压）
bevel gear 伞齿轮
block diagram 方框图
blue print 蓝图　
booster (pump) 增压泵
booster tran- 增压变压器
boring machine 镗床
bracket (tensile rod) for cooler 冷却品托架
braided wire 辫子线
brake　 包闸
brazing pliers 铜焊钳夹
brazing tran- 钎焊变压器
brazing transformer 铜焊机
breather 呼吸品
breboard (fibretube) 碳化纤维纸板（管）　fi
bridge for testing of voltage transformation ratio 变比电桥
bright bolt 光螺杆（螺母）
bright washer 光垫圈　
British thermal unit 英制热量单位
broaching machine 拉床
bulging lathe 旋压车床　
burden of an instrument transformer 互感器的负荷
bushing current tran- 套管用电流互感器
bus-type current tran- 母线式电流互感器
butt joint core 对接铁心
button head cap screw 无头螺杆
cable clip 电缆夹
cable paper 电缆纸　
cable through type HV bushing 穿缆式高压套管
calendered insulating paper 压延绝缘纸
calibration 校准
calvanized bolt 镀锌螺栓
capacitor compensation device 电容补偿装置
capacitor shield winding 插入电容式线圈
capacitor type current tran- 电容式电流互感器
capacitor type current tran- 电容式电压互感器
capstan and pulley block 绞盘与滑轮组
carbon monoxide 一氧化碳
Cartesian coordinate 笛卡儿坐标
cartridge of oil-filer 油过滤芯子
cascade testing transformer 串级式试验变压器
case No. 箱号
cast resin (resin moulded) transformer 塑料浇注变压器
cast resin current tran- 塑料浇注式互感器
caterpillar crane 履带吊
Celsius(centigrade) , Kelvin 摄氏度, 开尔文
center of gravity 重心　
CGS unit 厘米－克－秒 单位制
chain block 手拉葫芦
check on connection group (polarity) 联结组（极性）校验
chevron gear 人字齿轮
chopped wave lighting impulse 截波雷电冲击
chopping device 截断装置
chromatography 气相色谱分析
circular (internal)grinder 外圆（内圆）磨床
circularity (ellipticity) 圆度（椭圆度）
circumscribed circle of core leg 芯柱外接圆
clamping ring for porcelain casing 瓷箱压圈
clear away burrs 去毛刺
clear away welding flux 消除焊药皮
clear away welding splashes 消除焊渣飞溅
co2 protected welding CO2保护焊
coach bolt 方头螺拴　
coated with two layers of primer 涂两遍底漆
coiled spring　 盘簧　
cold bending machine for profiles 形材冷弯机
cold pressing pliers 冷压焊钳
cold rolled grain oriented silicon sheet steel 冷轧晶粒取向硅钢片
colloidal contamination of oil 油的胶体污染
colorimeter 比色计
coloured kerosene leakage test 火油着色试漏
combined instrument tran- 组合式互感器
combined voltage variation 混合调压
commissioning test 投运试验
complement angle 余角
complete self-protected single-phase tran- 全自动保护单相变压器
complete substation 成套变电站
complex number 复数
component (assembly) parts 部件　
composite conductor 复合导线
composite error 复合误差
compressing bolt with spring (hydraulic damper) 弹簧压钉（油缸压钉）
computer aided design and manufacturing 计算机辅助设计
computer aided test 计算机辅助实验
concrete (cement) reactor 水泥电抗器
condenser paper 电容器纸
conductance , conductivity 电导
conformity 合格
connecting box for fan-motors 风扇接线盒
connecting flange for evacuation (for oil filter) 真空接头（滤油接头）
conservator with rubber diaphrage(bladder) 带隔膜储油柜
consignee 收货人
consignor 发货人
constant flux voltage variation(C.F.V.V.) 恒磁通调压
container transport 集装箱运输　
contents of drawing (documents) 图样目录
continuous winding 连续式线圈
control box (panel) 控制箱（盘）
control point 控制点
conventer transformer 变流变压器
copper (aluminium) foil 铜（铝）箔
copper (brass , bronze , phosphor bronze) 紫铜（黄铜，青铜，磷铜）　
copper height of winding 铜线高度
copper tape 铜带
copper wire screen 铜网
core earthing strip 铁芯接地片　
core lamination 铁心片
core limb 铁心柱
core surface perpendicular to lamination 铁芯端面
core type 芯式
cork rubber 软木
corona discharge 电晕放电
Coulomb 库仑
coupling 联轴器
cover plate (temporary) 盖板（临时）
creepage distance 爬电距离
creeping discharge 沿面放电（爬电）
critical process 关键工序
cross-linked polymer cable 胶联聚合物电缆
crown nut 槽顶螺母　
crucible 蒸发器皿
cup head bolt 半圆头螺栓
current density 电流密度
current tran- 电流互感器
current voltage error 电流电压误差
cycloidal gear 摆线齿轮
cylindarical gear 圆柱齿轮
cylindrical insulating barrier of HV bushing 高压套管绝缘护筒
decimal 小数
deep-throat punching machine 深颈冲床
delivery date 发货日期
deoxygenized copper conductor 无氧铜导线
department 部门
design code 标准号
design review 设计评审
designating plate , illustration plate 标志牌，指示牌
designed , checked , approved 设计，校核，审定　
destination 到站
detail list of drawing 零件明细表　
detail list of purchased parts 外购件明细表
dew point measurement 露点测量
dielectric constant 介电常数
dielectric loss 介质损耗
dielectric strength insulation strength 绝缘强度
differential , differentiation 微分
differential gear 差动齿轮
digital display voltmeter 数字电压表
directed forced oil circulation cooling 油导向冷却
directed forced oil circulation forced air cooling 油导向吹风冷却
disk saw 圆锯床　
disk winding 饼式线圈（双饼线圈）
dismantle of upper yoke 拆除上轭
dismantled accessories 拆卸附件
dismountable parts　 可拆卸件
dispatch list 发货单
disruptive discharge 破坏性放电
distribution transformer 配电变压器
diverter switch 切换开关
dler gear　 空转齿轮i
don’t turn over 不准倒置
don’tstack up 不准叠放
double column punching machine 龙门冲床
double cotton covered enamel cable 双丝包线
double housing planer 双柱龙门刨
double-action punching machine 双动冲床
double-row bearing 双列滚珠轴承
draining valve 放油活门
drawing No. 图号
drill 钻床
drilled together with mating parts 与配合件同时钻孔
driving mechanism of OLTC 有载开关操作系统
dry type transformer 干式变压器
drying and compressing of winding 线圈的干燥与压缩
drying with hot-air circulation 循环热风干燥
duplicates 复制图
eads clamping (supporting frame) 引线夹（支架）
earthed voltage tran- 接地电压互感器
earthing mark 接地标志
earthing screen of core (side yuoke) 铁芯地屏（旁轭地屏）
earthquake , seism 地震
eccentricity (concentricity) 偏心度（同心度）
eddy current loss 涡流损耗
edge shaping 刨边
elastic washer 碟形弹簧
electrostatic plate (ring) 静电板（环）　
electrostatic shielding 静电屏蔽
enameled wrapped conductor 漆包线　
end insulation 端绝缘
engaging angle 压力角
engaging tooth 啮合齿
epoxy-bound bandage 环氧绑扎带
error 误差
error compensation 误差补偿
esiccator　 干燥管　d
ethylene 乙烯
evenness 整齐度　
evolute core 渐开线铁心
evolution extraction of root 开方
examination and appraisal program 检验鉴定大纲
expander 膨胀器
explosion-proof pipe 安全气道（防爆筒）
exponent , exponential 幂
extrapolation method 外推
eyebolt 吊环螺丝
facing boring lathe 落地镗床
Farad , pico-farad 法拉, 皮克法拉
faraday cage 法拉第笼
farthing bushing (terminal) 接地套管（端子）
feasibitilystudy 可行性分析
ferrous metal (non-ferrous metal) 黑色金属（有色金属）
filament tran- 灯丝变压器
final assembly 总装配
final inspection 最总检验
finalization of design 设计定型
finalized revision 定形改版
finish　(roughness) 表面光洁度(粗糙度)
finite element method 有限元法
first item inspection 首件试验
flame-proof tran- 防爆变压器
flash point (congealing point )of oil 油闪点（凝固点）
flashover 闪络
flask 长颈瓶　
flat washer 平垫圈
flatness 平（不平）度　
flexible cable 软电缆
flexible connecting strip 软接线片
floating crane 浮吊　
flow quantity (m³/min) 流量
flow relay 流动继电器
fluorescent leakage test 荧光试漏
flux density 磁通密度
foil winding 箔式线圈　
foot 呎
foot pad 垫脚　
for unmarked 其余　
for unmarked edges 其余倒角
forced oil air cooling (water cooling) 强油风冷（水冷）
forging (die casting) 煅件（压铸件）
fork lift 叉车　
form-fit tank 适形油箱
foundation drawing 地基图
fraction, numerator, denominator 分数，分子，分母
fractional turn (integer turn) 分数匝（整数匝）
frequency meter 频率表
frequency response 频率响应
full thread bolt 全螺纹螺拴
full wave lighting impulse 全波雷电冲击
furnace transformer 电炉变压器
gallon 加仑
galvanized 镀锌　
gas (moisture) content of oil 油中含水量（含气量）
gas cutting (automatic gas cutting) 气割
gas insulated transformer 气体绝缘变压器
gas relay 气体继电器
gas separating property of oil 油的吸气性
gate (butterfly,ball) valve 闸阀（蝶阀，球阀）
gauss 高斯
gear 齿轮　
gear slotting 插齿机
general layout 总图　
general parts 外购件
generator transformer 发电机变压器
Geneva (spider , universal joint cross) 方向联（十字接头）
gentian violet 龙胆紫　
glass fibre woven tape 玻璃丝带
glass-fibre covered conductor 玻璃丝包线
gorse power 马力
graphic method 图解法
gravitational acceleration 重力加速度
grinder 磨床
grinding to flat after welding 焊后磨平
grip nut 夹紧螺母
gross weight 毛重　
hack saw 弓锯床
hand hole (manhole) 手孔（人孔）
handled with care 小心轻放
hard drawn copper conductor 硬拉铜导线
hardening 淬火　
heavy current bushing 大电流套管
helical gear , screw gear 斜齿轮
helical winding 螺旋式线圈
here in after referred as XX 以下简称为XX
hexagonal head bolt 六角头螺栓
hexagonal socket head bolt 内六角头螺栓　
high frequency 高频
high vacuum period 高真空阶段
high voltage 高压示波器
high voltage (low, mid-) winding 高压线圈（中压，低压）
high-density pressboard 高密度纸板
hinge pin 胶联销
hoisting crane 起重机
horizontal oil-duct 横向油道
hot (hottest) spot 热点(最热点)
hot dipping 热浸
hot-oil circulation 热油循环
hot-rolled (cold-rolled) silicon sheet steel 热轧（冷轧）硅钢片　
hydraulic jacks for winding compression 线圈油压千斤顶
hydraulic planer 液压刨床
hydraulic pump station 油压泵站
Hysteresis loss 磁滞损耗
iacquer showering 淋漆（喷漆）
ickling　 酸洗
illustrative drawing 示意图
illustrative drawing for winding connection 线圈连接组图
illustrative drawing for winding terminals 线圈端子位置示意图
imaginary number component 虚数部分
impedance voltage 阻抗电压
improper fraction 假分数
impulse voltage generator 冲击电压发生器
inclination 倾斜度　
inconcentricity 不同心度
indication mark 指示标记　
induced over voltage withstand test 感应耐压试验
inductivemethod 归纳法
infrared scanner 红外线扫描仪
infrared scanning 红外线扫描
inhibited (un-) oil 阻化油（非阻化油）
initial terminal (final terminal ) of winding 线圈起始端（终）
inner connecting stud of HV bushing 高压套管导杆头
in-process inspection 工序间试验
installation drawing 安装图
instruction for technical design 技术设计说明书
insulating cylinder 绝缘纸筒
insulating filling strips between turns 线匝间垫条
insulating level 绝缘水平
insulating material (heat-resistant material) 绝缘材料（保温材料）
insulating paper (press board) 绝缘纸（纸板）
insulation angled ring (collar ring) 绝缘角环
insulation assembly 绝缘装配
insulation between turns 匝间绝缘
insulation breakdown 绝缘击穿
insulation diaphragm on the tank wall 箱壁绝缘隔板
insulation resistance 绝缘电阻
insulation wrapping 绝缘包扎
integrate , integration 积分
intensity of pressure 压强
interconnecting transformer 联络变压器
interleaved winding 纠结式线圈
interleaved-continuous winding 纠结－连续式线圈
internal external insulation 内外绝缘
interpolation method 插入法
introduction voltage regulator 感应调压器
involute gear 渐开线齿轮　
involution 乘方
involve to the fifth power , 5th power of n n的五次方
iron core reactor 铁心电抗器
iron red epoxy primer 环氧铁红底漆
isolation tran- 隔离变压器
jig boring machine 坐标镗床
joint flange for enclosed bus-bar 封闭母线联接法兰
Joule 焦耳
kerosene evaporator 煤油蒸发器
kerosene recycling pump 煤油回收泵
kilometer 公里
kilowatt-hour 千瓦时
kraft paper 牛皮纸（青壳纸）
lacquer of amidoalkyd base 胺基醇酸漆
lacquer of nitrocellulose 硝基漆（硝基清漆）　
lacquer thinner 稀释剂　
ladder with balustrade 有围栏的梯子
lag bolt 水螺丝
laminated pressboard 层压纸板
lamination drawing diagram 铁心叠积图
lamination factor 叠片系数
lamination inserting knife 插板刀
large size long layer winding 大型层式线圈
lathe 车床
layer insulation (insulation between disk) 层绝缘（段）　
layout 刻线
lead (tin, silver, zinc) 铅（锡，银，锌）
lead insulation wrapping machine 引线绝缘包扎机
leakage lest on sealed parts 密封式滤
lift 扬程
lifting lug (lifting eyebolt) 吊拌（吊环）
lifting lug with bearing plate for jacks 吊板与千斤顶支座
Liter , cubic decimeter 升, 立方分米
load loss 负载损耗
loading capacity 装载量
local over hot 局部过热
locating pin 定位销
locking nut 梭螺母
locking washer 止退垫圈
long-creepage bushing 加强式套管
longitudinal insulation 纵绝缘
loss tangent 介损角的正切值
low carbon steel (alloy steel) 低碳钢（合金钢）
low power factor wattmeter 低功率因数瓦特表
lug washer 止退线圈
machine direction 抄纸方向
magnetic flaw detection 磁力探伤
magnetic saturation voltage regulator 磁饱和调压器
magnetic shielding 磁屏蔽
magnetic type oil-level indicator 磁铁式油位指示器
main insulation 主绝缘
major (minor) diameter of gear 齿轮外（齿底）直径
marine tran- 船用变压器
market survey 市场调查
marshalling yard 铁路编组站
mating parts 配合件
maximum likelihood method 最大似然法
maximum minimum 最大，小
measuring flask 量瓶
medium frequency 中频
memory scope 记忆示波器
metallic hose 金属软管
metallized paper (crepe paper) 金属化纸（金属化皱纹纸）
meter , decimeter , centimeter millimeter 米, 分米, 厘米, 毫米
methane, ethane 甲烷（乙烷）
mile , knot 英里, 海里
miller 铣床
mining tran- 矿用变压器
modulus 模数　
moulded insulatingparts 成型绝缘件
movable (trailer mounted) type 移动式（列车式）
movable oil purificator 移动式净油站
movable radial drilling machine 移动式摇臂转床
movable substation 移动式变压器
moving-coil voltage tran- 移圈调压器
multi-point spot welder 多点焊机
name 名称　
natural cooling (air blast cooling) 自然冷却（吹风冷却）
natural frequency of vibration 自振频率
neutral bushing 中点套管
Newton , dyne 牛顿, 达因
nikel 镀镍　
nitrocellulose lacquer 硝基漆
niversal miller　 万能铣床u
no-load current 空载电流
no-load loss 空载损耗
nominal value 标称值
nonconformity 缺陷
non-distructive flaw detection 无损探伤
noninflammable medium impregnated trans- 浸难燃油变压器
normal distribution 正态分布
northeast china ash tree 水曲柳　
n-shaped clips for upper yoke 轭片Ｎ型夹
number item 项号
number of ampere-turns 安匝数
numerical control lathe 数控车床
nut locked by punching three points 冲铆三点锁紧螺母
nut of compressing bolt 压钉螺母
obtuse (acute) number 钝锐角
Oersted 奥斯特
ogee washer 曲面垫圈
oil base (paraffin base ,naphthene base) 油基（石蜡基，环烷基）
oil conduit 导油管
oil impregnation under vacuum 真空浸油
oil sampling valve (plug) 油样活门
oil tester 油试验器
oil-dehydrating device 油脱水装置
oil-duct air ventilating duct of core 铁心油道（气道）
oil-immersed air cooling 油浸风冷
oil-immersed forced directed oil circulation air cooling 油浸强
